BEAST - Governed Execution for Agentic Coding

BEAST is a local governance layer for coding agents. It sits between an agent,
your repository, local tools, MCP clients, and model providers. Models can
propose work, but BEAST owns the hard parts: context selection, policy checks,
safe patch compilation, verification, rollback evidence, provider routing, and
reusable compute.

The current upgrade turns BEAST from a collection of strong subsystems into a
more coherent agentic IDE runtime:

• Code Cortex is now the default front door for code context.
• SourcePlan is the governed edit and apply path.
• Mission Lattice can scaffold replay candidates without auto-applying them.
• CapabilityPlane unifies skills, plugins, commons candidates, exchanges, and
  local capability evidence.
• Evidence Bus indexes the proof chain and supports operational lookup.
• The TUI exposes clearer code panes, hunk selection, policy decisions,
  verification state, rollback status, and lattice replay candidates.
• MCP and HTTP surfaces share the same policy, source, context, and capability
  planes.

Models propose. BEAST scopes, gates, compiles, verifies, records, learns, and
rolls back.

Why BEAST Exists

Coding agents fail when they are given too much freedom and too little local
structure. Common failure modes include full-file rewrites for tiny edits,
stale context, invalid JSON, unsafe shell commands, provider confusion, hidden
test failures, and tool calls that produce no useful evidence.

BEAST changes the contract:

1. The agent receives a bounded, task-shaped view of the workspace.
2. The model returns structured intent, not arbitrary file mutations.
3. BEAST compiles that intent into local SourcePlans.
4. Policy gates decide what is allowed before changes land.
5. Verification, rollback, and evidence closure become first-class outputs.
6. Successful patterns can be reused through the Mission Lattice and compute
   governor, but only through gated replay.

What Changed In The Gortex Upgrade Cycle

This branch absorbed the useful architectural lessons from Gortex-style code
intelligence while keeping BEAST's stronger governance model.

Code Intelligence

Code Cortex now acts as the central code-context facade. WorkspaceGraph,
Gortex/local indexers, symbol lookup, file summaries, dependents, and edit
impact analysis are treated as adapters behind a single route:

GET  /edgek/code-cortex/status
GET  /edgek/code-cortex/symbols
GET  /edgek/code-cortex/file-summary
GET  /edgek/code-cortex/dependents
GET  /edgek/code-cortex/editing-context
POST /edgek/code-cortex/symbol-plan
POST /edgek/workspace/context

/edgek/workspace/context now carries context_front_door = "code_cortex" and enriches context packets with Code Cortex files, symbols,
impact, and receipts.

SourcePlan Workbench

SourcePlan is the operator-safe edit loop:

POST /edgek/sourceplan/scorecard
POST /edgek/sourceplan/preview
POST /edgek/sourceplan/verify
POST /edgek/sourceplan/apply
POST /edgek/sourceplan/lattice-replay

The scorecard now carries a Source Workbench view model with:

• selected hunks and code-pane state
• policy gate decision
• verification plan and status
• rollback path
• evidence closure path
• lattice replay candidate details
• CapabilityPlane hints

The TUI supports keyboard and mouse selection, click-to-select hunks,
double-click toggles, clearer diff visibility, and a more compact cockpit.

Mission Lattice Replay

The Mission Crystal Lattice identifies reusable edit patterns from proven
SourcePlan evidence. It no longer stops at advisory similarity. It can now
build a replay-gated scaffold:

lattice match -> SourcePlan scaffold -> policy gate -> verification plan
-> evidence closure

Replay is deliberately non-destructive. It does not auto-apply changes. Replay
outcomes are fed back into provider edit fitness and scheduler economics.

POST /edgek/mission-lattice/replay-scaffold

CapabilityPlane

CapabilityPlane is the single read facade for capability routing and promotion.
It combines:

• Capability Registry
• Skill Tree
• Plugin Marketplace
• Capability Exchange
• Meta Tool Commons
• local reusable capability evidence

Routes and tools can now ask one question: which capabilities are available,
verified, local, reusable, risky, or promotion-ready?

GET  /edgek/capability-plane/summary
POST /edgek/capability-plane/query

Evidence Bus

Evidence Bus indexes SourcePlan packets, policy decisions, lattice closures,
and replay evidence so MCP, TUI, and HTTP callers can query the same proof
chain.

GET  /edgek/evidence-bus/summary
POST /edgek/evidence-bus/query
POST /edgek/evidence-bus/related

Useful filters include task id, plan id, artifact type, source, status, and
relationships such as "everything related to this SourcePlan apply".

Policy Gates

BEAST now normalizes policy decisions across the major gates:

• Mode Router
• Spec Covenant
• Safety Governor
• SourcePlan
• Output Governor
• Agent Passport

The goal is one policy decision shape everywhere, so cockpit/source workbench
views can show one operator-readable answer instead of scattered local checks.

Route Modularization

The FastAPI surface has been split into route families while preserving public
paths:

app/routes/sourceplan.py
app/routes/compute.py
app/routes/workspace.py
app/routes/commons.py
app/routes/cockpit.py
app/routes/policy.py

app/main.py still contains legacy handlers during the transition, but module
routes are mounted first and active duplicates are removed at startup. Tests
assert that the important paths are owned by app.routes.*.

Core Architecture

How This Improves BEAST

The upgrade meaningfully improves BEAST in five ways.

First, code intelligence is less fragmented. Context flows through Code Cortex,
which makes TUI, MCP, HTTP, and SourcePlan decisions easier to compare and
debug.

Second, edits are more visible. The Source Workbench now shows the actual code
and diff state, selected hunks, policy results, verification state, rollback,
and evidence closure instead of hiding those details inside backend packets.

Third, reuse is operational instead of magical. Mission Lattice can suggest and
scaffold replay, but every replay still goes through SourcePlan, policy,
verification, and evidence closure.

Fourth, routing has a stronger capability model. CapabilityPlane lets BEAST
reason over local skills, plugins, commons candidates, verified capabilities,
and risk from one surface instead of scattered registries.

Fifth, the system is easier to maintain. Route families now have clear
ownership, active duplicate paths are suppressed, and tests lock down the
new ownership boundaries.

Quick Start

git clone https://github.com/Byron2306/EdgeK-BEAST.git
cd EdgeK-BEAST
pip install -r requirements.txt

Optional LiteLLM proxy support:

pip install -r requirements-litellm.txt

Start the gateway:

uvicorn app.main:app --host 0.0.0.0 --port 8005

Health check:

curl http://127.0.0.1:8005/health

Point an OpenAI-compatible agent at BEAST:

export OPENAI_BASE_URL=http://localhost:8005/v1

Point an Anthropic-compatible agent at BEAST:

export ANTHROPIC_BASE_URL=http://localhost:8005

Launch the TUI:

python3 -m app.cli.ui

Provider Setup

Set the provider keys you want BEAST to route across:

export XAI_API_KEY='...'
export OPENROUTER_API_KEY='...'
export HF_TOKEN='...'
export NVIDIA_API_KEY='...'
export MISTRAL_API_KEY='...'
export COHERE_API_KEY='...'
export GEMINI_API_KEY='...'

Unconfigured providers are skipped cleanly. Provider fitness is tracked
separately from BEAST-rescued completion, so the system can distinguish clean
model performance from local rescue.

Important Endpoints

# Gateway
GET  /health
GET  /edgek/state
GET  /ui

# Drop-in provider surfaces
POST /v1/chat/completions
POST /v1/messages
POST /hf/v1/chat/completions
POST /litellm/v1/chat/completions

# SourcePlan
POST /edgek/sourceplan/scorecard
POST /edgek/sourceplan/preview
POST /edgek/sourceplan/verify
POST /edgek/sourceplan/apply
POST /edgek/sourceplan/lattice-replay

# Code Cortex and workspace
GET  /edgek/code-cortex/status
GET  /edgek/code-cortex/symbols
GET  /edgek/code-cortex/file-summary
GET  /edgek/code-cortex/dependents
GET  /edgek/code-cortex/editing-context
POST /edgek/workspace/context
POST /edgek/workspace/index

# Mission cockpit, evidence, lattice
GET  /edgek/mission-cockpit/summary
GET  /edgek/mission-lattice/summary
POST /edgek/mission-lattice/lookup
POST /edgek/mission-lattice/replay-scaffold
GET  /edgek/evidence-bus/summary
POST /edgek/evidence-bus/query
POST /edgek/evidence-bus/related

# Capability and policy
GET  /edgek/capability-plane/summary
POST /edgek/capability-plane/query
GET  /edgek/mode-router/catalog
POST /edgek/spec-covenant/compile
POST /edgek/safety-governor/classify-command

# Compute and commons
GET  /edgek/compute
GET  /edgek/compute/metrics
GET  /edgek/crystal-compute
GET  /edgek/meta-tool-commons
GET  /edgek/commons-spaces
GET  /edgek/federated-commons

# MCP broker and runtime
POST /edgek/mcp/evaluate
POST /edgek/mcp/execute
GET  /edgek/mcp/audit
GET  /edgek/runtime/state
GET  /edgek/runtime/attempts

MCP Tools

The MCP runtime exposes BEAST operations directly to agent clients, including:

• beast_sourceplan_scorecard
• beast_sourceplan_preview_hunks
• beast_sourceplan_apply_selected
• beast_code_cortex_editing_context
• beast_capability_plane_summary
• beast_capability_plane_query
• beast_evidence_bus_query
• beast_mission_lattice_replay_scaffold

Tool allowlists can be constrained with the existing BEAST MCP environment
controls when running in stricter modes.

Benchmarks And Evidence

BEAST keeps local benchmark and proof artifacts under benchmarks/results/ and
.beast/evidence/.

Useful checks:

python3 -m pytest tests/test_agent_scheduler_mission_cockpit.py \
  tests/test_mission_crystal_lattice.py \
  tests/test_capability_plane.py \
  tests/test_context_packet.py -q

Broader reintegration checks:

python3 -m pytest tests/test_policy_gate_result.py \
  tests/test_reintegration_evidence_bus.py \
  tests/test_mission_crystal_lattice.py \
  tests/test_agent_scheduler_mission_cockpit.py \
  tests/test_spec_covenant_safety.py \
  tests/test_mode_router_worktree_forge.py \
  tests/test_mcp_runtime_v2.py \
  tests/test_sourceplan_bridge.py \
  tests/test_sourceplan_evidence.py \
  tests/test_code_cortex.py \
  tests/test_context_packet.py \
  tests/test_capability_plane.py \
  tests/test_output_governor.py \
  tests/test_memory_hull_residue_passport.py -q

Configuration

policies/default.yaml controls local operating rules:

• provider budgets and token caps
• shell command allowlists and blocklists
• write restrictions
• MCP trust and approval rules
• circuit breaker thresholds
• tool laziness and capability promotion behavior
• policy gate defaults

Local BEAST state is stored under .beast/ unless a route or client is given a
different workspace root.

What BEAST Does Not Do

• It does not replace model providers. It governs how agents use them.
• It does not silently apply lattice replay. Replay is scaffolded, gated, and
  verified.
• It does not share source code with Commons. Commons exchanges privacy-safe
  capability evidence and local adoption remains policy-gated.
• It does not treat a rescued patch as clean model success. Clean provider
  performance and BEAST-rescued reliability are tracked separately.

Status

Active development. The current system has moved beyond the original gateway:
it is now a governed coding-agent runtime with Code Cortex, SourcePlan,
CapabilityPlane, Evidence Bus, Mission Cockpit, Mission Lattice replay, and
crystallized compute feedback loops.

The remaining cleanup direction is mostly hardening: retire old inline route
bodies from app/main.py, broaden end-to-end TUI/MCP/HTTP replay tests, and
continue migrating any direct graph/context callers into Code Cortex.

License

MIT - see LICENSE.
