LiteDB

A modern, fast, and user-friendly database viewer/editor built with React and Tauri (Rust). Now supporting both SQLite and PostgreSQL with seamless database management and advanced vector search capabilities.

Features

• Schema Visualization: Visualize your database structure, relationships, and foreign keys in an interactive diagram.
  • Auto-Layout: Automatically arranges tables to minimize crossing lines.
  • Export: Save your schema diagram as PNG or SVG for documentation.
• Edit Support: View and edit database records directly
• Advanced Search: Filter and search through your data
• Real-time Updates: Changes reflect immediately
• Data Sorting: Sort any column with a click
• Responsive Design: Works great on any screen size
• Batch Operations: Execute multiple SQL statements with transaction support
• SQL Script Management: Save and reuse your SQL scripts
• Dual Database Support: Works with SQLite and PostgreSQL
• AI Agent (Text-to-SQL): Turn natural language into SQL queries.
  • Privacy-First AI: 100% Local Text-to-SQL support with Ollama.
  • Supports OpenAI, GitHub, and Azure providers.
  • Schema is injected into the LLM upon initialization and refresh.
• Autosave & Export: Automatically save changes and export query results to CSV, Excel, or JSON.
• Vector Search & Semantic Search: Perform semantic similarity searches on your data using pgvector and local embedding models.

Schema Visualization

LiteDB now includes a powerful Entity Relationship Diagram (ERD) generator:

1. Interactive Graph: Drag and drop tables, zoom in/out, and explore relationships.
2. Visual Foreign Keys: Lines connect Foreign Keys (Source) to Primary Keys (Target) automatically.
3. Key Indicators: Visual icons for Primary Keys (🔑), Foreign Keys (🔗), and Unique constraints (#).
4. Export Ready: One-click export to high-quality images for your technical documentation.

Vector Search & Semantic Search

LiteDB integrates advanced vector search capabilities powered by pgvector and local embedding models:

1. Semantic Search: Find similar rows based on vector embeddings.
   • Search by Row ID: Find rows that are semantically similar to a specific record.
   • Search by Text: Enter natural language queries to find relevant records using local embedding models.
2. Local Embedding Models: Run embedding models locally in your browser/app using Transformers.js.
   • Supported models: all-MiniLM-L6-v2, bge-base-en-v1.5, bge-large-en-v1.5.
   • Privacy-first: No data is sent to external APIs for embedding generation.
3. Distance Metrics: Support for multiple distance metrics to suit your data:
   • Cosine Distance (<=>): Best for normalized vectors.
   • L2 Distance (<->): Euclidean distance.
   • Inner Product (<#>): Dot product (negative).
4. Visual Feedback: Color-coded similarity bars to quickly identify the most relevant results.

AI Architecture (Text-to-SQL)

Unlike standard API wrappers, LiteDB implements a Context-Aware RAG Pipeline to ensure high-accuracy SQL generation:

1. Schema Extraction: On connection, the app actively introspects the database to extract table definitions, foreign keys, and data types.
2. Dynamic Context Injection: This metadata is formatted and injected into the LLM's system prompt (System Message), giving the model "awareness" of the specific database structure.
3. Driver-Specific Validation: The system prompts are tailored to the active driver (e.g., enforcing PostgreSQL specific syntax vs. SQLite), reducing syntax errors in generated queries.

Tech Stack

• React
• TypeScript
• Vite
• Tailwind CSS
• Tauri (Rust)
• PostgreSQL
• SQLite

Getting Started

Prerequisites

• Node.js (v16 or higher)
• Rust (latest stable)
• PostgreSQL (if using PostgreSQL features)

Installation

1. Clone the repository:

git clone https://github.com/createdbyadham/LiteDB

1. Install dependencies:

npm install

1. Start the development server:

npm run tauri dev

Building for Production

npm run tauri build

Usage

Connecting to Databases:

1. SQLite: Click "Upload Database" or drag & drop your SQLite file
2. PostgreSQL: Open the Connection Manager, enter your credentials, and connect
3. Switch Databases: Use the database switcher to toggle between SQLite & PostgreSQL
4. Browse tables using the table selector
5. Use the search bar to filter data
6. Double-click any row to edit
7. Check multiple rows at once then click "Delete" to remove them
8. Click "Save Changes" to persist modifications

PostgreSQL-Specific Features:

• Run SQL queries with real-time feedback
• View table structures directly in the UI
• Batch execute multiple statements in transaction mode
• Securely connect using SSL

Batch Operations & SQL Scripting

The batch operations feature allows you to execute multiple SQL statements at once, which is perfect for complex database operations.

Using Batch Operations

1. After loading a database, click on the "Batch Operations" tab
2. Enter your SQL statements in the editor, separating them with semicolons (;)
3. Use the "Use Transaction" toggle to enable/disable transaction mode:
   • When enabled (default): All statements succeed or none do (atomic operations)
   • When disabled: Each statement is executed independently
4. Click "Execute Script" to run your SQL commands
5. View the results including execution time, affected tables, and any errors

Saving and Reusing Scripts

1. Write your SQL script in the editor
2. Enter a name for your script in the input field
3. Click "Save Script" to store it for future use
4. Access your saved scripts by clicking on the "Saved Scripts" tab
5. Use the "Load" button to load a script back into the editor
6. Delete unwanted scripts with the delete button

Example Scripts

Here are some example SQL scripts you can try:

Create new table and insert data:

CREATE TABLE users (
  id INTEGER PRIMARY KEY,
  name TEXT NOT NULL,
  email TEXT,
  age INTEGER
);

INSERT INTO users (id, name, email, age) VALUES (1, 'name-example1', '[email protected]', 32);
INSERT INTO users (id, name, email, age) VALUES (2, 'name-example2', '[email protected]', 28);

Update and delete records:

UPDATE users SET age = 33 WHERE name = 'John Doe';
DELETE FROM users WHERE name = 'Jane Smith';

Schema modifications:

ALTER TABLE users ADD COLUMN created_at TEXT;
UPDATE users SET created_at = datetime('now');
CREATE INDEX idx_users_name ON users (name);

Complex operations with transaction:

BEGIN TRANSACTION;
CREATE TABLE temp_users AS SELECT * FROM users;
UPDATE users SET age = age + 1;
INSERT INTO users SELECT * FROM temp_users WHERE age > 30;
DROP TABLE temp_users;
COMMIT;

Development

Project Structure

src/
  ├── components/     # React components
  ├── hooks/         # Custom React hooks
  ├── lib/           # Utilities and services
  ├── styles/        # Global styles
  └── types/         # TypeScript type definitions

Contributing

1. Fork the repository
2. Create your feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add some amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.
