Emberglow 🔥⌨️

Light your Keychron Q10 based on what Claude is doing. Emberglow turns your
keyboard's RGB into an ambient status light:

It talks to the keyboard over the VIA protocol (QMK raw HID) — no extra
software, no OpenRGB server. It was built for Claude Code, but the CLI
(emberglow set <state>) is tool-agnostic, so any agent that can run a command
on lifecycle events can drive it:

• Claude Code hooks → the CLI: emberglow set needsyou
• Anthropic (Managed Agents) webhooks → the server: emberglow serve
• OpenAI Codex CLI and Google Antigravity → their notify/hook systems
  (see below)

Requirements

• A Keychron Q10 on wired USB (raw HID isn't exposed over Bluetooth/2.4GHz).
• Python 3.10+.
• The VIA app/tab closed while Emberglow runs — only one process can hold the
  raw-HID interface at a time.

Supported keyboards

Emberglow is built and tested against the Keychron Q10, but nothing in the
lighting engine is Q10-specific — the VIA protocol (QMK raw HID) it speaks is
shared across VIA-enabled QMK boards. Any such board should work once you point
Emberglow at it:

1. emberglow enumerate — find the board's USB VID/PID and its raw-HID
   interface (usage_page=0xFF60).
2. emberglow probe — discover the firmware-specific effect indices
   (breathing / solid) by flashing each one.
3. Plug those values in — see docs/PROTOCOL.md for exactly
   what to change.

Got another board working? A PR adding it to this table is welcome.

Install

git clone https://github.com/emberglow-dev/emberglow-keyboard
cd emberglow-keyboard
python -m venv .venv
# Windows:  .venv\Scripts\activate      macOS/Linux:  source .venv/bin/activate
pip install -e .

Verify the keyboard is reachable:

emberglow enumerate     # should list a "QMK raw-HID interface" line for the Q10
emberglow status        # prints the VIA protocol version + current lighting

One-time setup: find your effect indices

Effect indices are firmware-specific (they match your VIA lighting dropdown
order). Discover which index is the breathing effect:

emberglow probe         # cycles effects; note which index breathes

Then set the two indices Emberglow uses (defaults: solid=1, breathing=2):

# Windows (persist):  setx KB_BREATHING_EFFECT 2   &&  setx KB_SOLID_EFFECT 1
export KB_BREATHING_EFFECT=2
export KB_SOLID_EFFECT=1

Use it with Claude Code hooks (local, no server)

This is the simplest path — Claude Code runs a shell command on lifecycle events.
Add this to ~/.claude/settings.json (all projects) or .claude/settings.json
(this project). Full copy in examples/claude-code-settings.json:

{
  "hooks": {
    "UserPromptSubmit": [
      { "hooks": [{ "type": "command", "command": "emberglow set working" }] }
    ],
    "Notification": [
      { "hooks": [{ "type": "command", "command": "emberglow set needsyou" }] }
    ],
    "Stop": [
      { "hooks": [{ "type": "command", "command": "emberglow set done" }] }
    ]
  }
}

What each hook maps to:

• UserPromptSubmit → working (blue): you sent a prompt, Claude is on it.
• Notification → needsyou (amber breathing): Claude is waiting on you
  (a permission prompt, or it's been idle waiting for input).
• Stop → done (green flash, then your normal lighting comes back).

If emberglow isn't on your global PATH (e.g. it's in a venv), point the hook
at the wrapper in examples/emberglow-hook:

{ "hooks": [{ "type": "command", "command": "/abs/path/to/examples/emberglow-hook needsyou" }] }

Windows gotcha: Claude Code runs hook commands through Git Bash, where \
is an escape character. Use **forward slashes** in any absolute path, or the
path silently collapses (C:\Users\... → C:Users... → "command not found"):

{ "hooks": [{ "type": "command", "command": "C:/Users/you/emberglow-keyboard/.venv/Scripts/emberglow.exe set needsyou" }] }

Test a hook by hand — it's just the CLI:

emberglow set needsyou     # keyboard breathes amber
emberglow set done         # green flash, then restores your lighting

Use it with OpenAI Codex CLI

Codex CLI can run an external program on lifecycle events via the notify
option in ~/.codex/config.toml, passing the event as a JSON string in the
program's final argument. Today Codex emits only the agent-turn-complete
event — it fires when Codex finishes a turn and hands control back to you — so
the natural mapping is turn-complete → needsyou.

~/.codex/config.toml:

notify = ["python3", "/abs/path/to/emberglow-notify.py"]

emberglow-notify.py:

#!/usr/bin/env python3
"""Codex `notify` bridge → Emberglow. Codex passes the event as JSON in argv[1]."""
import json, subprocess, sys

if len(sys.argv) >= 2:
    try:
        event = json.loads(sys.argv[1])
    except json.JSONDecodeError:
        event = {}
    if event.get("type") == "agent-turn-complete":
        # Codex finished the turn and is waiting on you.
        subprocess.run(["emberglow", "set", "needsyou"], check=False)

Limitation: Codex's notify currently exposes only agent-turn-complete,
so there's no native "started working" signal. To also light working, wrap
the codex command in a shell alias/function that runs emberglow set working
before launching Codex.

Payload fields are documented in the Codex
advanced configuration docs.

Use it with Google Antigravity

⚠️ Verify against the current docs before relying on this. Antigravity's
hooks are documented on a JavaScript-rendered site that couldn't be read
verbatim; the config below is corroborated from Google Cloud Community and
third-party write-ups, not confirmed against the primary docs. Treat the
exact event names and file paths as probably right, worth double-checking.

Antigravity supports hooks — shell commands run on agent lifecycle events —
defined in a hooks.json file, either globally
(~/.gemini/antigravity-cli/hooks.json) or per workspace
(<project>/.agents/hooks.json). Reported events include PreInvocation,
PostInvocation, PreToolUse, PostToolUse, and Stop.

{
  "emberglow-working": {
    "PreInvocation": [
      { "hooks": [ { "type": "command", "command": "emberglow set working", "timeout": 10 } ] }
    ]
  },
  "emberglow-done": {
    "Stop": [
      { "hooks": [ { "type": "command", "command": "emberglow set done", "timeout": 10 } ] }
    ]
  }
}

Two Antigravity-specific caveats:

• Unlike Claude Code / Codex fire-and-forget hooks, Antigravity hooks are
  decision gates: the script reads event JSON on stdin and is expected to
  emit an allow/deny JSON verdict on stdout and exit 0. For a pure side
  effect like emberglow set, run the command, then print an "allow" response.
• No lifecycle event corresponding to "waiting for your approval/input" is
  confirmed, so needsyou may not be expressible here yet.

Use it with Anthropic webhooks (Managed Agents)

Anthropic POSTs signed events when a session changes state. Emberglow verifies
the signature and lights the board.

1. Register the endpoint in the Anthropic Console → Manage → Webhooks.
   Subscribe to session.status_*, deployment_run.*, etc. Copy the
   whsec_... signing secret it shows once.

2. Run the server with that secret in the environment:

   # Windows (persist): setx ANTHROPIC_WEBHOOK_SIGNING_KEY whsec_xxx
   export ANTHROPIC_WEBHOOK_SIGNING_KEY=whsec_xxx
   emberglow serve                 # listens on 0.0.0.0:8787, POST /webhook


3. Expose it publicly so Anthropic can reach it (any tunnel works):

   cloudflared tunnel --url http://localhost:8787
   # or:  ngrok http 8787


   Put the resulting https://.../webhook URL in the Console.

The event → state mapping lives in emberglow/states.py
(EVENT_STATE). Unmapped events are acknowledged and ignored, so subscribing to
extra event types is harmless.

Local testing without a real webhook

KB_ALLOW_UNVERIFIED=1 emberglow serve
curl -X POST http://localhost:8787/test/needsyou     # fire a state by hand

KB_ALLOW_UNVERIFIED=1 disables signature checks and enables the /test/<state>
route. Never enable it on a public endpoint.

CLI reference

emberglow set <working|needsyou|done|failed>   apply a lighting state
emberglow restore                              restore pre-takeover lighting
emberglow status                               VIA protocol version + lighting
emberglow probe [--count N] [--hold S]         cycle effects to find breathing
emberglow enumerate                            list Keychron HID interfaces
emberglow serve [--host H] [--port P]          run the webhook server

Environment variables: KB_BREATHING_EFFECT, KB_SOLID_EFFECT,
ANTHROPIC_WEBHOOK_SIGNING_KEY, KB_ALLOW_UNVERIFIED, PORT.

Development

pip install -e ".[dev]"
pytest                  # unit + e2e (no hardware needed)
pytest -m hardware      # also flash each state on a connected board

• Unit tests use a fake HID device — no keyboard required.
• E2E tests run the real Flask server on a socket and post genuinely-signed
  webhooks over HTTP.
• Hardware tests are opt-in (-m hardware) and briefly flash the real board.

Architecture, the VIA protocol, and how to contribute are documented in
CLAUDE.md, CONTRIBUTING.md, and
docs/.

License

MIT — see LICENSE.
