GoPeak

GoPeak Hero

GoPeak is an MCP server for Godot that lets AI assistants run, inspect, modify, and debug real projects end-to-end.

Discord community chat is temporarily unavailable while the invite link is refreshed. Please use GitHub Discussions in the meantime: https://github.com/HaD0Yun/Gopeak-godot-mcp/discussions

Quick Start (3 Minutes)

Requirements

Godot 4.x
Node.js 18+
MCP-compatible client (Claude Desktop, Cursor, Cline, OpenCode, etc.)

1) Run GoPeak

npx -y gopeak

or install globally:

npm install -g gopeak
gopeak

Optional shell hooks for update notifications are now opt-in:

gopeak setup

gopeak setup only modifies supported bash/zsh rc files when you run it explicitly. npm install no longer installs shell hooks automatically.

2) Add MCP client config

{
  "mcpServers": {
    "godot": {
      "command": "npx",
      "args": ["-y", "gopeak"],
      "env": {
        "GODOT_PATH": "/path/to/godot",
        "GOPEAK_TOOL_PROFILE": "compact"
      }
    }
  }
}

GOPEAK_TOOL_PROFILE=compact is the default. It exposes 33 core tools with 22 dynamic tool groups (78 additional tools) that activate on demand — keeping token usage low while preserving full capability.

3) First prompts to try

"List Godot projects in /your/projects and show project info."
"Create scenes/Player.tscn with CharacterBody2D root and add a movement script."
"Run project, get debug output, then fix top error."

Why GoPeak

Real project feedback loop: run the game, inspect logs, and fix in-context.
110+ tools available across scene/script/resource/runtime/LSP/DAP/input/assets.
Token-efficient by default: compact tool surface (33 tools) + dynamic tool groups. Only activate what you need — no more 110-tool context bombs.
Dynamic tool groups: search with tool.catalog and matching groups auto-activate. Or manually activate with tool.groups.
Deep Godot integration: ClassDB queries, runtime inspection, debugger hooks, bridge-based scene/resource edits.

Best For

Solo/indie developers moving quickly with AI assistance
Teams that need AI grounded in actual project/runtime state
Debug-heavy workflows (breakpoints, stack traces, live runtime checks)

Tool Surface Model (Important)

GoPeak supports three exposure profiles:

compact (default): 33 core tools + 22 dynamic tool groups (78 additional tools activated on demand)
full: exposes full legacy tool list (110+)
legacy: same exposed behavior as full

Configure with either:

GOPEAK_TOOL_PROFILE
MCP_TOOL_PROFILE (fallback alias)

Dynamic Tool Groups (compact mode)

In compact mode, 78 additional tools are organized into 22 groups that activate automatically when needed:

Group	Tools	Description
`scene_advanced`	3	Duplicate, reparent nodes, load sprites
`uid`	2	UID management for resources
`import_export`	5	Import pipeline, reimport, validate project
`autoload`	4	Autoload singletons, main scene
`signal`	2	Disconnect signals, list connections
`runtime`	4	Live scene inspection, runtime properties, metrics
`resource`	4	Create/modify materials, shaders, resources
`animation`	5	Animations, tracks, animation tree, state machine
`plugin`	3	Enable/disable/list editor plugins
`input`	1	Input action mapping
`tilemap`	2	TileSet and TileMap cell painting
`audio`	4	Audio buses, effects, volume
`navigation`	2	Navigation regions and agents
`theme_ui`	3	Theme colors, font sizes, shaders
`asset_store`	3	Search/download CC0 assets
`testing`	6	Screenshots, viewport capture, input injection
`dx_tools`	4	Error log, project health, find usages, scaffold
`intent_tracking`	9	Intent capture, decision logs, handoff briefs
`class_advanced`	1	Class inheritance inspection
`lsp`	3	GDScript completions, hover, symbols
`dap`	6	Breakpoints, stepping, stack traces
`version_gate`	2	Version validation, patch verification

How it works:

Auto-activation via catalog: Search with tool.catalog and matching groups activate automatically.

"Use tool.catalog with query animation and show relevant tools."
Manual activation: Directly activate a group with tool.groups.

"Use tool.groups to activate the dap group for debugging."
Deactivation: Remove groups when done to reduce context.

"Use tool.groups to reset all active groups."

The server sends notifications/tools/list_changed so MCP clients (Claude Code, Claude Desktop) automatically refresh the tool list.

Don't worry about tokens

GoPeak uses cursor-based pagination for tools/list — even in full profile, tools are delivered in pages (default 33) instead of dumping all 110+ definitions at once. Your AI client fetches the next page only when it needs more.

Set page size with GOPEAK_TOOLS_PAGE_SIZE:

{
  "env": {
    "GOPEAK_TOOLS_PAGE_SIZE": "25"
  }
}

Installation Options

A) Recommended: npx

npx -y gopeak

B) Global install

npm install -g gopeak
gopeak

Optional shell hooks for update notifications remain available via:

gopeak setup

C) From source

git clone https://github.com/HaD0Yun/Gopeak-godot-mcp.git
cd godot-mcp
npm install
npm run build
node build/index.js

GoPeak also exposes two CLI bin names:

gopeak
godot-mcp

Documentation

CI

GitHub Actions runs on push/PR and executes:

npm run build
npx tsc --noEmit
npm run smoke

Run the same checks locally before opening a PR:

npm run ci
npm run test:dynamic-groups
npm run test:integration

Versioning & Release

Use the built-in bump script to keep package.json and server.json in sync:

node scripts/bump-version.mjs patch
node scripts/bump-version.mjs minor --dry-run

Full release checklist: docs/release-process.md.

Addons (Recommended)

Auto Reload + Editor Bridge + Runtime Addon installer

Install in your Godot project folder:

curl -sL https://raw.githubusercontent.com/HaD0Yun/Gopeak-godot-mcp/main/install-addon.sh | bash

PowerShell:

iwr https://raw.githubusercontent.com/HaD0Yun/Gopeak-godot-mcp/main/install-addon.ps1 -UseBasicParsing | iex

Then enable plugins in Project Settings → Plugins (especially godot_mcp_editor for bridge-backed scene/resource tools).

Core Capabilities

Project control: launch editor, run/stop project, capture debug output
Scene editing: create scenes, add/delete/reparent nodes, edit properties
Script workflows: create/modify scripts, inspect script structure
Resources: create/modify resources, materials, shaders, tilesets
Signals/animation: connect signals, build animations/tracks/state machines
Runtime tools: inspect live tree, set properties, call methods, metrics
LSP + DAP: diagnostics/completion/hover + breakpoints/step/stack trace
Input + screenshots: keyboard/mouse/action injection and viewport capture
Asset library: search/fetch CC0 assets (Poly Haven, AmbientCG, Kenney)

Tool families (examples)

Area	Examples
Project	`project.list`, `project.info`, `editor.run`
Scene/Node	`scene.create`, `scene.node.add`, `set_node_properties`
Script	`script.create`, `script.modify`, `script.info`
Runtime	`runtime.status`, `inspect_runtime_tree`, `call_runtime_method`
LSP/DAP	`lsp.diagnostics`, `lsp_get_hover`, `dap_set_breakpoint`, `dap.output`
Input/Visual	`inject_key`, `inject_mouse_click`, `capture_screenshot`

Project Visualizer

Visualize your entire project architecture with visualizer.map (map_project legacy). Scripts are grouped by folder structure into color-coded categories.

Project Visualizer — AI-generated architecture map

Quick Prompt Examples

Build

"Create a Player scene with CharacterBody2D, Sprite2D, CollisionShape2D, and a basic movement script."
"Add an enemy spawner scene and wire spawn signals to GameManager."

Debug

"Run the project, collect errors, and fix the top 3 issues automatically."
"Set a breakpoint at scripts/player.gd:42, continue execution, and show stack trace when hit."

Runtime testing

"Press ui_accept, move mouse to (400, 300), click, then capture a screenshot."
"Inspect live scene tree and report nodes with missing scripts or invalid references."

Discovery & dynamic groups

"Use tool.catalog with query tilemap and list the most relevant tools."
"Activate the dap tool group for breakpoint debugging with tool.groups."
"Find import pipeline tools with tool.catalog query import and run the best one for texture settings."
"Reset all active tool groups with tool.groups to reduce context."

Technical Reference

Environment variables

Name	Purpose	Default
`GOPEAK_TOOL_PROFILE`	Tool exposure profile: `compact`, `full`, `legacy`	`compact`
`MCP_TOOL_PROFILE`	Fallback profile env alias	`compact`
`GODOT_PATH`	Explicit Godot executable path	auto-detect
`GODOT_BRIDGE_PORT`	Bridge/Visualizer HTTP+WS port override (aliases: `MCP_BRIDGE_PORT`, `GOPEAK_BRIDGE_PORT`)	`6505`
`DEBUG`	Enable server debug logs (`true`/`false`)	`false`
`LOG_MODE`	Recording mode: `lite` or `full`	`lite`
`GOPEAK_TOOLS_PAGE_SIZE`	Number of tools per `tools/list` page (pagination)	`33`
`GOPEAK_BRIDGE_PORT`	Port for unified bridge/visualizer server	`6505`
`GOPEAK_BRIDGE_HOST`	Bind host for bridge/visualizer server	`127.0.0.1`

Ports

Port	Service
`6505` (default)	Unified Godot Bridge + Visualizer server (+ `/health`, `/mcp`) on loopback by default
`6005`	Godot LSP
`6006`	Godot DAP
`7777`	Runtime addon command socket (only needed for runtime tools)

Minimal port profiles

Core editing only: bridge port (GODOT_BRIDGE_PORT, default 6505)
Core + runtime actions (screenshots/input/runtime inspect): bridge port + 7777
Full debugging + diagnostics: bridge port + 6005 + 6006 + 7777

Troubleshooting

Godot not found → set GODOT_PATH
No MCP tools visible → restart your MCP client
Project path invalid → confirm project.godot exists
Runtime tools not working → install/enable runtime addon plugin
Need a tool that is not visible → run tool.catalog to search and auto-activate matching groups, or use tool.groups to activate a specific group
