Mermaid diagrams, tables and code, drawn in color right in Claude Code.

Install · Performance · Themes · Features · Configure · Changelog

TL;DR

• merman is a Claude Code mod: a plugin of TypeScript hooks that redraws what Claude Code shows on screen. It is not a tool or MCP server, and Claude never calls it.
• Claude Code prints mermaid as source and tool calls as walls of text. merman draws them: real charts and flowcharts, typeset LaTeX math in kitty and Ghostty, colored tables and code, and, if you opt in, quiet tool rows.
• 16 palettes plus mono, and copy buttons on everything.
• One command to install, /plugin to turn it off. Claude Code's own renderer comes back the moment you do.
• No network calls. It runs a program only when you click ⧉ html or ▣ png (the clipboard helper) or turn on LaTeX (RaTeX's renderer).
• A full reply renders in about 2 ms; see Performance.

Install

Requires Claude Code 2.1.311 or later. One line in your shell:

claude plugin marketplace add iamrohithrnair/merman && claude plugin install merman@merman

Or inside Claude Code:

/plugin marketplace add iamrohithrnair/merman
/plugin install merman@merman

Then start a new session, or run /reload-plugins in an open one, and run /merman setup to pick a theme and styles, then /merman demo for a tour.

In a terminal, setup opens a pane: the arrows or Tab move through the styles of a step with a preview of the one in focus, Enter saves it and shows the next step. Where the session has no terminal, as in the desktop app, it walks the same steps in the transcript.

Update, disable, uninstall

The install follows tagged releases. To update to the latest one:

claude plugin marketplace update merman && claude plugin update merman@merman

Then run /reload-plugins in every open session. A session keeps what it loaded until it reloads.

To turn it off or on, run claude plugin disable merman@merman or claude plugin enable merman@merman, or use /plugin. To remove it:

claude plugin uninstall merman@merman

From a checkout

To run the latest main, or your own changes, link a clone into Claude Code's skills folder instead. It loads in place as merman@skills-dir, so whatever the checkout has is what draws; git pull and /reload-plugins update it. Uninstall the marketplace copy first so the two don't both load.

git clone https://github.com/iamrohithrnair/merman.git && cd merman
mkdir -p "${CLAUDE_CONFIG_DIR:-$HOME/.claude}/skills"
ln -s "$PWD" "${CLAUDE_CONFIG_DIR:-$HOME/.claude}/skills/merman"

To remove it, delete the link: rm without -r removes only the link, not the checkout.

rm "${CLAUDE_CONFIG_DIR:-$HOME/.claude}/skills/merman"

For LaTeX math, install RaTeX's renderer and set latex to true; see LaTeX math. Until then formulas draw as text.

Performance

merman draws replies in place of Claude Code's own markdown renderer, so its cost is the time to turn a reply into a tree, plus a one-time note to the model.

What	Median	p95
Full demo reply (headings, tables, code, 7 diagrams), first draw	2.3 ms	3.0 ms
Same reply, redrawn	0.35 ms	0.45 ms
One redraw while an 18 KB reply streams in	1.4 ms	2.5 ms
300-row table	2.4 ms	3.0 ms
800-line highlighted code block	0.98 ms	1.6 ms
Markdown parse of the demo reply	0.07 ms	0.08 ms

Measured with npm --prefix scripts run bench (200 runs, Node 24, Apple M4 Pro). A 60 Hz frame is 16.7 ms, so even a long reply leaves most of the frame free.

• Redraws: finished replies keep their drawing and are reused when only their place on screen changes, so scrolling back does not redraw them.

• C4 layout: merman routes C4 lines itself, in about 1 ms for 5 to 10 boxes and 30 to 45 ms for 30 boxes and 40 relationships at the 80-line cap. The router stops after a fixed amount of work, about 100 ms, and lists what it has not reached in the legend.

• Screen size: the demo reply draws in 996 nodes, 5% of Claude Code's 20000-node limit per tree. A 500-line highlighted file uses 38%. Past 18000 nodes a reply drops C4 hover groups first, then draws its heaviest code blocks plain.

• Tokens: merman's only model-facing cost is the diagramHints note, added once to the first prompt of a conversation and again only after a compaction drops it. Like any message it then stays in the conversation's context, where prompt caching covers it on later turns. Replies, tool output and redraws add nothing.

  Part	Tokens
  Main note (what merman draws)	about 135
  Figure rules	about 220
  LaTeX line, only while latex is on	about 55
  Total	about 355, or 410 with LaTeX

  Set diagramHints to false and merman sends nothing to the model. See Diagram hints.

• Size: 656 KB of hooks on disk, 220 KB of it the bundled mermaid and Prism engines. No network calls.

Features

Feature	What you get
Themes	/merman theme <name> switches on the spot. 17 themes and 20 color slots you can override
Tables	colored headers, rules, column alignment, colored numbers, sized to the terminal
Code	a language header and copy button, Prism highlighting in two dozen languages, shell lines colored like a prompt
Diagrams and charts	flowcharts, sequence, state, class, ER and C4 diagrams, bar and line charts, one color per box, participant and bar
Figures	```figure text pictures drawn as written in the theme's colors, for timelines, layouts and before and after; glyphs and markup checked before they are drawn
LaTeX math	$$ and ```math formulas typeset as images in kitty and Ghostty by RaTeX, text everywhere else
Layout	back-to-back tables and diagrams sit side by side and wrap on narrow terminals
Copy buttons	⧉ md, ⧉ art, ⧉ html and ▣ png on tables, [ ⧉ copy ] on code, lists and quotes, /merman copy without a mouse
Tool rows	Opt-in with toolRows: true: Ran gh pr view 12, Read ~/src/app.ts, groups summed up as Ran 3 commands, read 2 files, with status dots; toolOutput: quiet hides what Claude only read and says in plain words what each call did
Slash commands	command output (/cost, /context, plugin commands) gets the same tables and code styling
Diagram hints	a short model-only note, once per conversation, so Claude reaches for diagrams, charts and figures when they help, and builds explaining replies around the pictures
Text	bold, italic, strikethrough, inline code, links, versions, durations, percentages and clickable paths in their own colors
Headings, lists, quotes	4 heading styles, nested lists, task lists, quotes with an accent bar
Your prompts	what you type draws in a bubble, an accent bar or a chevron, so you find your turns when you scroll back, and clock adds when you sent it
Right to left	Hebrew and Arabic read right to left, with bullets, quote bars and table columns mirrored
Other mods	$.merman.markdown draws any markdown the way replies are drawn, for mod authors

Themes

Dark: catppuccin-mocha (default), dracula, nord, tokyo-night, gruvbox-dark, rose-pine, everforest, github-dark, one-dark, solarized-dark, neon.

Light: catppuccin-latte, gruvbox-light, rose-pine-dawn, github-light, solarized-light.

mono drops the palette for bold and dim; alerts keep their colors. Switch with /merman theme nord, or run /merman for the help screen with every theme. Every palette is MIT licensed and credited in THIRD_PARTY_NOTICES.md.

Tables

Header cells take the tableHeader color, and the default box style puts a double line under the header. tableStyle picks box (the default, every cell boxed), rules, grid or minimal. :---: and ---: alignment is honored, numbers in cells get the number color, and columns shrink to fit the terminal.

Code

Each code block gets a header row: the language on the left, a copy button on the right. The code sits indented below with no frame, so selecting it with the mouse copies only the code.

• Prism highlights JavaScript, TypeScript, JSX/TSX, Python, Go, Rust, Java, Kotlin, Swift, C, C++, C#, Ruby, JSON, YAML, TOML, SQL, HTML, CSS, Dockerfile, HCL, Lua and diff.
• Shell blocks (bash, sh, zsh, fish, powershell, unlabeled) color the command word, --flags, quoted strings and # comments, and restart after |, && and ;.

Diagrams and charts

Code blocks tagged mermaid draw as colored text art:

• flowcharts (graph LR, graph TD, decisions), sequence, state, class and ER diagrams
• bar and line charts with xychart-beta, sized to the terminal width
• C4 context, container, component, dynamic and deployment diagrams, laid out by merman itself: each box shows its name in bold, its type in brackets ([Container: Go]) and its description, boundaries and deployment nodes draw as frames inside frames, and external elements draw in the comment color. Each relationship is a numbered line, and a legend under the diagram spells out who talks to whom, the label and the technology; dynamic diagrams number their steps in order, and relationships between the same two boxes in the same direction share one line labelled with all their numbers, like 1,3. Pointing at a line or its legend row lights both. A relationship from a box to itself, one with no free path or no room for its number, or one the router has not reached when it stops, is listed in the legend in the comment color with no line, and so is every relationship of a diagram whose boxes alone are wider than the terminal. The same C4 written for C4-PlantUML draws from a plantuml or puml block: merman skips the @startuml, !include, LAYOUT_…, SHOW_LEGEND() and skinparam lines, draws what is inside together and package groups in place, breaks lines at \n, and draws the rest, with no Java or PlantUML involved; other PlantUML stays a code block. An alias defined twice draws once, the way mermaid draws it: with its last label, inside the boundary of its last definition. Boxes wrap onto more rows and the legend onto more lines to fit the terminal, titles wrap, a frame label too long for its frame ends in …, and text without spaces, like Chinese, breaks between characters; a diagram still streaming in shows as source until its fence closes. Style and layout statements (UpdateElementStyle, Rel_U, Lay_R) are skipped; a relationship that points at a boundary rather than a box, boundaries nested more than 16 deep, or a picture too big to lay out leave the diagram as source
• pie charts as a circle with a colored legend, largest slice first, and gantt schedules as bars on a shared date or time axis, starting on a half cell and ending on an eighth so close durations draw apart
• each box and participant gets its own theme color, the same at both ends of a sequence diagram
• bars in a multi-series chart get their own colors; a single-series chart prints each value above its bar and colors the tallest one
• gridlines stay dim, axis numbers use the number color

pieStyle picks how a pie draws. round falls back to bars in ascii mode, with more slices than the theme has distinct colors (mono always) or in a narrow terminal:

round (default)	bars
a circle, each slice in its own color, with a legend	one bar per slice, largest first, with its share

Diagrams too wide for the window, or over 80 lines, stay as code. mermaidAscii swaps box-drawing characters for + - |.

Figures

Some things read better as a picture than as a diagram: a timeout racing a retry, the layout of a screen, a system before and after a change. Code blocks tagged figure draw line by line as written, in the theme's colors:

The markdown Claude wrote for it

```figure
{dim:timeout at 10 s, handler books at 12 s, retry books again}
          {note:0 s}           {note:10 s}  {note:12 s}              {note:later}
          {accent:▏─────────────▏─────▏─────────────────▏}
Provider  {accent:██████████████}{warn:✗} timeout               {accent:█} retry
Handler   {ok:████████████████████} 200, nobody waits
Bookings  0                   {ok:1}                 {warn:2 twice}
```

• {role:text} colors a run: accent for frames, lines and arrows (diagram color), warn for the break or the risk, ok for what is healthy or done, note for time and effort, dim for side notes (comment color), strong for the one thing that matters (strong color); the rest takes the diagram text color. warn, ok and note take the theme's reddest, greenest and most amber accent color, each a different one and none the diagram color, so a risk never looks like a frame line in any theme; hex and rgb() colors you set take part in that pick, and a role whose own slot (flag, string or heading color) you set to a color name or ansi256() keeps that color
• ▶ and ◀ draw as ► and ◄, as in diagrams, so no glyph turns into an emoji; in mono, warn draws bold
• a figure stays a code block while it streams (so a reply that opens with a figure shows its markup until the block closes), when it has more than 80 lines, when a line is wider than the window or than 100 columns, and when a line would not draw as written: a glyph that may draw as an emoji or takes two columns, a tab, a control character, a direction mark or another character that draws no column (a zero-width space, a soft hyphen), or role markup in the wrong case, misspelled, nested or left open; once the block is closed, a dim line above it says why, such as figure line 4: "⚠" may draw as an emoji, use a text glyph
• frames are not checked: a box that does not close or a side, corner or divider out of its column draws as written, as Claude typed it, so a frame that is slightly off still draws
• ⧉ source copies the block as Claude wrote it, ⧉ art the drawn text
• figures draw whether mermaid is on or off; only the diagram hints note follows mermaid
• Claude learns about figures from the diagram hints note: prefer a figure over mermaid when position carries meaning (durations racing on a time axis, a screen layout, phases, before and after); when you ask to explain, compare or plan something and pictures would make it easier to grasp, build the reply around them, with the core on the first screen; the prose does not retell the picture; then the roles, the width and the glyphs that draw cleanly; plain flows and charts stay mermaid

LaTeX math

Display math, $$…$$ on lines of its own or a ```math block, draws as a typeset image in the theme's diagram text color, one formula per line. With copy buttons on, its ⧉ copy button copies the formula's LaTeX, since selecting an image copies blank cells. It needs RaTeX's PNG renderer, a single binary that typesets KaTeX syntax in a few milliseconds without TeX, a browser or Node:

gh release download -R erweixin/RaTeX -p 'ratex-cli-*-aarch64-apple-darwin.tar.gz'
tar -xzf ratex-cli-*.tar.gz
mkdir -p ~/.local/bin
install ratex-cli-*/render ~/.local/bin/ratex-render

Pick the archive for your platform (x86_64-apple-darwin, x86_64-unknown-linux-musl, ...). Any directory on your PATH works, but the file must be named ratex-render.

LaTeX is off until you set latex to true. Then merman runs ratex-render once in kitty and Ghostty, outside tmux, or wherever CLAUDE_CODE_FORCE_TERMINAL_IMAGES makes Claude Code draw images, such as a background session viewed in one of them, and keeps LaTeX on only if that test formula comes back. If a later run fails, formulas already drawn stay and new ones stay text until you /reload. A reply shown before the test finishes draws its formulas as text, then redraws them as images. Anywhere else, without the renderer, or with latex off, formulas draw as text in a math code block. So does a formula the renderer rejects, or one too wide for the terminal even at one row. While LaTeX is on, the diagram hints note also tells Claude that $$ math renders. Inline $…$ draws as italic text without its dollar signs, with common commands such as \rho, \cdot and \le shown as symbols; amounts like $5 stay as written.

Formula text matches the reply text. A terminal image fills whole rows, so a formula that falls between two row counts is rendered again with more padding rather than stretched.

Layout

When tables, diagrams and figures follow each other, they share a row and wrap once the terminal runs out of width. A wide terminal shows a table, a flowchart and two charts side by side.

Copy buttons

• Tables: ⧉ md copies the original Markdown and ⧉ art a boxed table that pastes well into Slack. ⧉ html copies a formatted table (headers, alignment, inline formatting) plus a tab-separated plain-text copy.
• Code, lists and quotes: [ ⧉ copy ] on each. Code copies without its fences, lists as markdown, quotes without their > markers.
• Diagrams and figures: ⧉ source copies the mermaid or figure source, ⧉ art the drawn art.
• As an image: ▣ png on tables, diagrams and figures puts a PNG of the drawn art on the clipboard, monospace in the theme's text and background colors, ready to paste into Slack, docs or slides. It shows in a local macOS or Windows terminal and draws with the OS's own fonts (osascript on macOS, powershell.exe on Windows), so it needs nothing installed. If that fails, it copies the drawn text and the toast says why.
• Whole replies: replies with more than one block, or any Hebrew or Arabic, end with ⧉ copy reply, which copies the reply as Claude wrote it. Selecting right-to-left text on screen copies letters in drawn order, not reading order.
• No mouse: /merman copy copies the last reply, /merman copy code its last code block.

copyButtonStyle picks where the buttons sit. inline, the default, is the look above. hover puts a dim ⧉ beside each block's first row instead, at its left on a right-to-left block, and one in the reply's bottom-right corner for the whole reply. Pointing at a ⧉ draws its buttons over it, so they take no line and nothing moves when they show; the pointer on the block itself shows nothing. ctrl+x tab does not reach a hidden button, and the mobile app, which has no pointer, draws them inline.

⧉ html shows in a local macOS terminal or a Linux graphical session. macOS needs nothing extra. Linux needs CopyQ running (see its Wayland caveats). On Ubuntu:

sudo apt install -y copyq && copyq --start-server && copyq config autostart true

Clicking works where the terminal passes clicks through, as fullscreen mode does. Terminals with copy-on-select, such as Warp, may grab the word "copy" instead.

Tool rows

Tool rows are opt-in: by default Claude Code draws tool calls and their results itself. Set toolRows: true to have merman draw them as below; toolStyle, toolOutput and diffStyle apply only then.

Each tool call draws as one line: a verb and its target, Ran with a colored shell command, Read and Edited with the path, which opens the file on click like a path in a reply (see Text). A status dot shows done, running or failed, and output still draws below. Edits draw as a diff card in the theme's colors, and so do files a shell command changed (sed -i, a script), one card per file headed by its path. A file Write creates is no diff, as in Claude Code's own preview: Created <path> (N lines) heads its first 10 lines as numbered code in the theme's colors, and a click anywhere on it, title or lines, or on +N more lines opens the rest; show less or another click folds it again. A diff card or a new file's preview with lines folded away opens the same way. A file an Edit or a shell command creates shows its first 10 lines as added diff lines under the same header. A file a shell command deletes is one Deleted <path> (N lines) line, and a click on it opens its removed lines. A file moved unchanged is one Renamed <old> → <new> line. In the desktop app a click on the code lines does nothing; the +N more lines button does it. In diff cards added and unchanged lines are highlighted in the file's language, removed lines stay plain as in Claude Code, and when a line is edited rather than rewritten, the words that changed get a deeper tint. diffStyle picks the look: card (default) frames the lines in a rounded box, full drops the box and tints each changed line across the width, marks drops the tint and colors only the + and − marks, and bar puts a colored ▌ before each changed line.

card (default)	full	marks	bar
rounded box, tinted lines	no box, lines tinted across the width	no tint, colored + and −	no tint, a colored ▌ before each changed line

Collapsed groups draw one line too: Ran 3 commands, read 2 files · last: npm test (ctrl+o to expand), with · N failed in the flag color when any call failed. In the ctrl+o transcript every row and result draws in full, as Claude Code has it. Expand a group (ctrl+o or --verbose): shell calls keep their colored command with the output boxed below, and other calls use Claude Code's own rows. ctrl+o on a reply shows the original text.

toolStyle keeps tool rows apart from what Claude says:

chat (default)	tree-dim	tree-bold	classic
dimmed on the right, capped at 60% of the width	tucked under the sentence with ⎿, dimmed	tree-dim with one-line sentences in bold	bold verb and status dot, full brightness

toolOutput: quiet shows what Claude did, not what it read: reads, searches and read-only shell commands draw one plain row like Read src/report.py lines 1–10 and nothing under it. Edits keep their diff and failures show their real error; the full rules are in docs/tool-output.md.

Slash commands

Output from slash commands, built-in or from other plugins, is drawn like a reply, copy buttons included. Errors keep Claude Code's own red line.

Diagram hints

Claude rarely writes a chart unless it knows the terminal can draw one. With diagramHints on (the default), the first prompt you type or another plugin sends in a conversation carries a short note that only the model reads. The conversation keeps it, so later prompts carry nothing: it goes out again in a new conversation (/clear) and after a compaction drops it, never twice in a resumed conversation that still holds it, and its LaTeX math part rides the first prompt after the renderer is ready. Slash commands carry none. It says tables, alerts, code, mermaid diagrams and xychart-beta charts render here, asks for a chart with short labels where numbers or flows read better drawn, but none for short answers, code changes or reports and never a second picture of what a figure shows, and asks for commands and snippets in fenced blocks, never inline code, since only those get a copy button. A second part describes figures: use one where position carries meaning (a time axis, a screen layout, phases, before and after), keep mermaid for plain flows and charts, and never retell the picture in prose. Only when you ask Claude to explain, compare or plan something and pictures would help does it build the reply around them, core first. Then come the role markup, at most 74 columns so a figure fits an 80-column window, glyphs one column wide, and edge ticks ▏ for a time axis so █ bars line up.

The note costs about 355 tokens once per conversation: about 135 for the main part and about 220 for the figure part, plus about 55 while LaTeX math is on, when it also says $$ formulas render. It's off whenever mermaid is off, and skipped for the prompt a headless claude -p run starts with and for background notifications; a prompt another plugin sends inside such a run still carries it.

Text

Bold, italic, strikethrough, inline code, links and bare URLs, clickable as terminal hyperlinks. Numbers, versions (v2.14.0), durations (250ms, 3h), sizes (16Gi) and percentages (99.9%) take the number color, and paths like ~/src/app.ts the path color.

Paths open their file or folder on click, as do file:// links that show their own path. A path that starts with ~/, ./ or ../ links to its file, with ~ read as your home folder and ./ from the session's project folder. A path that starts with / links once it has two parts, like /tmp/app.ts, so a slash command like /config stays text, and so does a top folder like /tmp. A :12 after a path stays text. The files in tool rows of Claude Code's own file tools (Read, Edit, MultiEdit, Write, NotebookEdit, Grep, Glob) and the headers of shell-edit diff cards link too, a one-part path like /etc included, to the whole path even where the row shortens it. A file:// link shows its own path when its text, apart from trailing punctuation, is the link itself or the path the link opens: /tmp/a.md, C:\Users\me\a.md and \\server\share\a.md as written, or a ~/, ./ or ../ path read as above. A link with any other text, such as [the docs](file:///tmp/setup.command), draws as the docs (file:///tmp/setup.command) in plain text, so a reply cannot hide what a click opens behind a harmless name. Under WSL the link goes through wsl.localhost, so Windows Terminal opens the file from the Linux side; a Linux terminal under WSLg (GNOME Terminal, Konsole, kitty) gets plain file:/// links, which it opens itself. Paths link only in a terminal that draws hyperlinks, judged the way Claude Code judges it (FORCE_HYPERLINK, Windows Terminal, iTerm2, WezTerm, kitty, Ghostty, VS Code 1.72 and later, and others), so a terminal without them never shows a URL after each path. In a session over SSH (SSH_CONNECTION or SSH_TTY set) paths and file:// links stay text, since a file link would open a file on the computer the terminal runs on rather than the one Claude Code runs on. A link longer than the 2048 characters Claude Code draws stays text too. Paths in inline code stay plain, and the desktop app draws paths and file:// links as before.

Links that open a file in an editor are clickable: vscode://file/…, vscode-insiders://file/…, cursor://file/…, windsurf://file/… and zed://file/…, with an optional :line or :line:column. Other links of these editors stay text, the label then the target, since they reach extensions or actions such as cloning a repository or opening settings.

Programs and launchers never link, so a click on one cannot run it. A path, a tool row's file or a file:// link whose last name ends in one of these extensions stays text, a path in the path color and a file:// link as its text and target, and so does anything inside an .app bundle: on macOS .app, .command, .tool, .terminal, .pkg, .mpkg, .mobileconfig, .prefPane, .workflow, .action, .fileloc, .inetloc and .webloc; on Windows .exe, .com, .scr, .pif, .cpl, .msi, .msp, .msu, .msix, .msixbundle, .appx, .appxbundle, .appinstaller, .application, .appref-ms, .vsix, .bat, .cmd, .ps1, .psc1, .vbs, .vbe, .js, .jse, .wsf, .wsh, .wsc, .hta, .chm, .msc, .reg, .xll, .wsb, .diagcab, .ahk, .au3, .lnk, .url, .scf and .settingcontent-ms; on Linux .desktop, .sh, .bash, .zsh, .csh, .ksh, .run, .AppImage, .deb, .rpm, .snap, .flatpak and .flatpakref; and anywhere .jar, .jnlp, .py, .pyw, .pyz, .pyzw, .pyc, .pl, .rb and .rbw. Case does not matter, and neither does a trailing slash, a ?query or #fragment, percent-encoding, trailing dots or spaces, or an NTFS :stream after the name. So .js, .sh and .py files in a reply or a tool row do not open on click. The check reads names only: a program without one of these extensions, such as a Unix executable with no extension, still links, and an .html file still opens in the browser, scripts and all.

Footnotes draw as superscript marks, with the notes under a dim rule at the end of the reply. Click a mark, in a sentence, a list, a quote or a table cell, to see its note in a toast. Point at a note to light every mark that cites it, or at a mark to light its note. Clicks and pointing work where the terminal passes the mouse through, as fullscreen mode does, and in the desktop app.

Headings, lists, quotes

Terminals have one font size, so headings stand out through style and color. headingStyle picks the look:

banner (default)	bold	underline	uppercase
a box around H1, a heavy rule under H2	bold in the heading color	bold with H1 and H2 underlined	bold with H1 in capitals

Lists keep their numbers and nest with • and ◦. Quotes get an accent bar down every line and keep their paragraphs, lists, code, tables and nested quotes, and GitHub alerts (> [!NOTE], [!TIP], [!IMPORTANT], [!WARNING], [!CAUTION]) draw as colored boxes.

Task lists draw as [ ] and [✓], with done items dimmed and struck through. taskStyle switches to ticks (○ ✓), box (□ ✓) or progress, which adds a done-count bar above each list.

Your prompts

What you type, at the prompt or through Remote Control, draws in the theme's colors. promptStyle picks the look, and off keeps Claude Code's own. Task notifications and teammate messages are left alone.

bubble (default)	wide	bar	chevron
a prompt in a rounded box	a prompt in a rounded box across the full width	a prompt with an accent bar	a prompt with a bold chevron

clock adds the time each prompt was sent. The line that closes a turn is Claude Code's own, with its end time (✻ Baked for 1m 55s · done 14:32). It reads 24h or 12h, and a time from another day gets its date. With promptStyle: off the time goes in front of Claude Code's own prompt row. Off by default.

clock	on a prompt
24h	a prompt bubble that starts with the time it was sent
12h	a prompt bubble that starts with 5:45 PM

Right to left

Hebrew and Arabic blocks are right aligned, with bullets, numbers and quote bars on the right and table columns mirrored. Code, numbers, paths and links stay left to right inside them. Terminals treat right-to-left letters differently, so merman detects yours and sends the letters the way it needs them. /merman demo-rtl shows every element, and the rtl option forces a terminal's handling or turns it off.

Configure

Open /config and look for the merman rows, or set values in ~/.claude/settings.json:

{
  "pluginConfigs": {
    "merman@merman": {
      "options": {
        "theme": "tokyo-night",
        "tableStyle": "grid",
        "headingStyle": "banner",
        "tableHeaderColor": "#ffcc00",
        "numberColor": "cyan"
      }
    }
  }
}

Options sit under options, keyed by the plugin's id: merman@merman, or merman@skills-dir for a linked checkout. Project settings are not read for plugin options. From a shell, claude plugin configure merman@merman lists every option and which are set, and piping it a JSON object such as {"theme":"nord"} with --values-stdin saves those values.

Option	Values	Default
enabled	true, false	true
theme	see Themes, or random for a new dark color preset each time the mod loads	catppuccin-mocha
tableStyle	box, rules, grid, minimal	box
taskStyle	checks ([ ] [✓], done struck through), ticks (○ ✓), box (□ ✓), progress (ticks with a done-count bar)	checks
promptStyle	bubble, wide, bar, chevron, off	bubble
clock	off, 24h, 12h	off
headingStyle	banner, bold, underline, uppercase	banner
highlightNumbers	true, false	true
highlightPaths	true, false	true
toolRows	true, false	false
toolStyle	chat, tree-dim, tree-bold, classic	chat
toolOutput	full, quiet	full
copyButtons	true, false	true
copyButtonStyle	inline, hover	inline
diagramHints	true, false	true
rtl	auto, a terminal (warp, kitty, apple-terminal, iterm, ghostty, wezterm, vscode, alacritty, windows-terminal, gnome, konsole), off	auto
mermaid	true, false	true
mermaidAscii	true, false	false
pieStyle	round (a circle with a legend), bars (one bar per slice)	round
latex	true, false	false
<token>Color	any color, see below	theme
diffStyle	card (rounded box, tinted lines), full (no box, lines tinted across the width), marks (no tint, colored + and − marks), bar (no tint, a colored ▌ before each changed line)	card
A color is hex (#a6e3a1, #fc0), rgb(166,227,161), ansi256(114) or a name (green, cyanBright). Values that don't parse are ignored. Every token has a <token>Color option and a row in /config:

Token	Colors
accent	reply bullet, H3+ headings, quote bar, running tool dots
heading	H1 and H2
strong	bold text, strong in figures
emphasis	italic text, variables, attribute names
inlineCode	inline code
codeText	code block text
codeCommand	shell commands, functions, class names, keys
codeFlag	--flags, keywords, failures
codeString	strings
codeComment	comments, the code block's language label, dim in figures
link	links, URLs, properties, tags
path	file paths, regexes
number	numbers, versions, durations, done dots
quote	quote text
rule	rules, diff card borders, chart gridlines
tableHeader	table header cells
tableRule	table rules
bullet	list bullets and numbers
diagram	diagram lines, accent in figures
diagramText	diagram labels, LaTeX formulas and figure text
diffAdded	added diff lines: their tint, + marks and count (the theme's own green)
diffRemoved	removed diff lines: their tint, − marks and count (the theme's own red)

Troubleshooting

• A setting or update didn't take: run /reload. A session keeps what it loaded.
• A diagram shows as code: its source is over 80 lines or 8,000 characters, it's wider than the window, it doesn't parse, or mermaid is off. Widen the terminal or split the diagram.
• A figure shows as code: it is still streaming, it has more than 80 lines, a line is wider than the window or than 100 columns, or a line holds a glyph, character or markup that would not draw as written; the dim line above it names the line (see Figures). A frame that is slightly off draws as written, never as code. Widen the terminal, or ask Claude to fix the glyph or the markup.
• No ⧉ html on tables: you're over SSH, in the desktop app or VS Code, or on Linux with no graphical session. ⧉ md and ⧉ art still work.
• ⧉ html copied plain text only: CopyQ isn't running, or the clipboard helper failed. The toast says why.
• Clicking a copy button selects the word "copy": your terminal copies on select. Use /merman copy.

Limits

• The parser covers what Claude writes (headings, lists, tables, fences, quotes, emphasis, links). It's not full CommonMark: HTML draws as plain text, and a quote ends at the first line without >.
• Widths count CJK and emoji as two columns. Terminals disagree on a few emoji, so those can still be off by one.
• Languages outside the 24 above draw in codeText.
• Tested by hand in the macOS terminal; CI runs the tests on macOS, Linux and Windows. The desktop app, VS Code and mobile use the same mod API but are not checked by hand yet.

For LLMs and agents

To change the code, read AGENTS.md instead.

• What it is: a Claude Code mod (function hooks in TypeScript) that redraws assistant replies, slash-command output, tool rows (opt-in with toolRows), the turn footer and user prompts. It changes how things look, and with diagramHints on (the default) it also asks Claude to build a reply around pictures when they make it easier to grasp, with the core on the first screen as a picture or a sentence. The one thing it sends the model is the optional diagram hint below.
• Install: claude plugin marketplace add iamrohithrnair/merman && claude plugin install merman@merman, then /reload-plugins. Needs Claude Code 2.1.311+. For development, symlink a checkout to ~/.claude/skills/merman ($CLAUDE_CONFIG_DIR/skills/merman when that is set) instead; it loads in place as merman@skills-dir.
• Configure: /merman theme <name> and /merman setup set options at runtime. Every option is a key under pluginConfigs["merman@merman"].options (merman@skills-dir for a linked checkout) in ~/.claude/settings.json (or a row in /config), then /reload. Options and defaults are in the Configure table; the machine-readable source is userConfig in .claude-plugin/plugin.json. Color values that don't parse are ignored.
• Side effects: no network. Programs it runs: the ⧉ html and ▣ png clipboard helper (/usr/bin/osascript on macOS, powershell.exe on Windows, copyq on Linux for ⧉ html only, 5 second timeout, 15 on Windows, only on a click), and ratex-render while latex is on. With diagramHints on, it adds about 355 tokens of model-only context (about 410 while latex is on) once per conversation, to the first prompt you type or another plugin sends, and again after a compaction drops it, as broken down under Diagram hints.
• Turning it off: "enabled": false, or disable the plugin in /plugin.
• For other mods: $.merman.markdown({ surface, text, columns }), typed in types/index.d.ts. See Other mods.

Develop

git clone https://github.com/iamrohithrnair/merman
claude --plugin-dir ./merman

Edits hot-reload in that session. Before a PR run claude plugin validate . and claude plugin test ., and print docs/demo.md to check the look. npm --prefix scripts run bench times a full render of the demo reply, so speed claims can be checked on any machine. The full rules and verify loop are in AGENTS.md.

Other mods

Other mods can draw markdown in the user's theme with $.merman.markdown. Pass the surface, the text and the content width in columns.

• It answers the tree to draw, or undefined when merman is disabled or the text holds nothing to draw.
• It throws when merman isn't installed, so call it in a try.
• Merman draws at least 20 columns wide. Copy buttons are left out, because a button can't cross from one mod to another.

let drawn
try {
  drawn = await $.merman.markdown({ surface: e.surface, text, columns: e.props.bodyColumns })
} catch {}
return drawn ?? <Markdown text={text} />

The types are in types/index.d.ts. List merman under dependencies in your plugin.json and Claude Code lays them into your .claude-plugin/types/. When merman is optional, declare the noun in your own contract instead:

declare module 'claude-code' {
  interface EngineInterface {
    merman: {
      markdown: (args: { surface: RenderSurface; text: string; columns: number }) => Promise<RenderElement | undefined>
    }
  }
}

Author

Maintained by iamrohithrnair.

License

MIT. Bundled third-party code is listed in THIRD_PARTY_NOTICES.md.
