dsh-plugin-garmin-connect

A DeepSeek Harness plugin that brings your Garmin fitness & health data into the AI agent loop.

English | 简体中文 | Test Report | Changelog

Works with mainstream coding agents and AI workspaces
DeepSeek Harness · WorkBuddy · Qwen Work · ZCode · Claude Code · Codex · Cursor · Windsurf
_{Connect through MCP or a SKILL.md workflow, depending on the client.}

[!WARNING]
0.1.6-rc.1 experimental status: local dsh Web, the
garmin-connect-auth serve system-browser flow, and MCP URL elicitation can
now bootstrap the same owner-only session. Garmin two-step verification is
still a preview: a real China-region MFA browser-to-session-and-read chain
passed locally on 2026-08-29, while International-region MFA and refresh-token
rotation remain pending and browser policy may still block a flow. The older
login --browser command is retained only as a diagnostic.

---

More Apps

Icon	App	What it does
	WristTale	Read TXT and Markdown on your Garmin watch
	JiaKe.app	Turn Garmin screenshots into polished assets
	GameraSnap	Control your phone camera from your Garmin watch
	WristAlbum	Keep a private photo album on your Garmin
	WristPass	Keep cards and tickets ready on your wrist
	2FA4G	Keep offline 2FA codes on your Garmin

---

What It Does

This plugin connects DeepSeek Harness to Garmin Connect, exposing your wearable data as AI-callable tools. Once installed, the DeepSeek agent can automatically query your activities, sleep, steps, and heart rate to provide personalized fitness insights — all through natural language.

Registered Tools

The plugin registers 10 tools. Eight return Garmin data without writing;
download_garmin_activity_fit writes one local file on the MCP/dsh host, and
create_garmin_workout changes the user's Garmin workout library.

Tool	Description	Example Args
get_garmin_activities	Fetch recent activities (runs, rides, swims…) with compact or full detail	{"limit": 5, "detail": "compact"}
get_garmin_sleep	Sleep score, duration, and stage breakdown for a date or range	{"startDate": "2023-10-01", "endDate": "2023-10-02"}
get_garmin_steps	Step totals for a date or range; goal/distance appear only when Garmin supplies them	{"startDate": "2023-10-01"}
get_garmin_heart_rate	Resting, max, and min heart rate for a date or range	{"startDate": "2023-10-01", "endDate": "2023-10-02"}
get_garmin_weight	Body composition (weight, BMI, body fat %, muscle mass, etc.) for a date or range	{"startDate": "2023-10-01"}
get_garmin_workouts	Workout templates from your Garmin workout library (not calendar scheduling)	{"limit": 10, "offset": 0}
get_garmin_profile	User profile summary	{} or omit
get_running_skill_advice	Explain 8 workout types and 4 training philosophies, or collect the mandatory intake for personalized coaching	{"mode": "explain", "query": "Daniels", "language": "en"}
download_garmin_activity_fit	Download an activity's original archive and safely extract its single FIT file to the account directory under the configured host parent	{"activityId": 123456789}
create_garmin_workout	Preview a structured workout; create it only after explicit confirmation	{"name": "Threshold 3×8min", "steps": [...]}

Workout creation is a two-call flow. The preview response includes a one-time
confirmationId; after the user approves the unchanged preview, call the tool
again with the same definition, confirmed: true, and that confirmationId.
An ID expires after 10 minutes and cannot be reused.

Personalized running coaching

get_running_skill_advice deliberately separates explanation from planning:

• mode: "explain" explains a workout type or training philosophy. It does not
  invent an athlete-specific schedule.
• mode: "personalized" is required for any recommendation or plan. Before it
  returns planning material, the tool requires answers for all six intake areas
  below. Missing answers are returned as focused questions; Garmin activity data
  is not fetched and a schedule must not be generated yet.

Intake field	What the assistant must ask
goal	Target distance/event, future ISO YYYY-MM-DD date, and completion or ideal/minimum time goal
currentPerformance + performanceBasis	A representative race/time trial from the past two years, result, non-future date, effort/conditions, or an explicit no_recent_benchmark
trainingBackground	Running history and recent 4–8 week volume, frequency, long run, quality work, and interruptions
availability	Available days/time, fixed rest and long-run days, terrain/facility limits, strength-training time, and whether double days are possible
healthConstraints + hasWarningSymptoms	Current/past-year injury, pain, relevant disease/medication, sleep and recovery, plus an explicit warning-symptom boolean
trainingPreference + preference details	steady, hard_easy, or mixed, plus maxQualitySessionsPerWeek (0–7) and intensityGuidancePreference (pace, heart_rate, rpe, or mixed)

If hasWarningSymptoms is true—for example current chest discomfort,
unusual breathlessness with mild activity, fainting/dizziness, or abnormal
palpitations—the tool returns a safety stop without workout material or Garmin
activity access. It advises medical clearance and does not diagnose. If
performanceBasis is no_recent_benchmark, planning material instructs the
assistant to begin with easy base work or a low-risk benchmark instead of
inventing precise threshold or interval paces.

The compact philosophy layer contains:

• Hansons — frequent, more evenly distributed mileage, pace discipline, and
  cumulative fatigue; its 16-mile long run is not a standalone prescription.
• Jack Daniels — derive VDOT and E/M/T/I/R intensity from current, recent
  performance, never from the goal time.
• Norwegian threshold — borrow controlled, non-exhaustive threshold work and
  hard/easy separation; double-threshold days are not prescribed by default.
• Polarized training — keep most work genuinely easy and a small amount
  clearly hard; 80/20 is a direction rather than an exact quota.

Recent Garmin runs may supplement this intake but never replace the athlete's
answers. The method notes and evidence boundaries are summarized in
the training-method research note.
Each philosophy and workout-card output labels its statements as
system_principle, research_evidence, or application_inference so a method
definition or coaching inference is not misrepresented as comparative proof.

---

Quick Start

1. Install this plugin — from the npm registry (recommended)

npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add dsh-plugin-garmin-connect

This single command installs the dependency and activates the plugin layer — the first run automatically initializes the web profile. You only need pnpm on your PATH:

npm install -g pnpm

--legacy-peer-deps=false makes npm resolve peer dependencies normally. If your npm config has legacy-peer-deps=true (it skips peer packages), dsh would fail to boot with ERR_MODULE_NOT_FOUND: Cannot find package '@deepseek-ai/cordis-plugin-group'. On machines without that setting the flag is a harmless no-op.

Verify the plugin layer is composed without booting:

npx --legacy-peer-deps=false @deepseek-ai/dsh --profile web --dump-config | grep -A 2 garmin-connect

Other install sources:

# Local checkout (development)
cd garmin-connect-plugin-for-dsh && npm install
npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add .

# GitHub source install
npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add github:<owner>/<repo>

2. Install the Harness CLI (if you haven't already)

npx --legacy-peer-deps=false @deepseek-ai/dsh web

The web UI starts at http://127.0.0.1:3080 by default. If you launch Harness via npx, keep using the same prefix for the commands below (npx --legacy-peer-deps=false @deepseek-ai/dsh …); if you have dsh installed globally, you can drop the npx @deepseek-ai/ prefix.

3. Configure Credentials

Normal runtime credentials come from environment variables (or a secret store
provided by your launcher); keep .env out of version control. The experimental
local Web flow is the narrow exception: after explicit profile confirmation, the
Host atomically saves an owner-only DI session file. It never saves the password,
MFA code, or CAPTCHA response.

# Source checkout only: copy the bundled template
cp .env.example .env

# Edit .env and fill in your Garmin credentials

For a registry installation, create .env directly in the directory where you
run dsh (your workspace root), then add the variables from the table below;
the package's template is inside the installed dependency rather than your
current directory. The plugin loads the workspace .env automatically.

Variable	Required	Description
GARMIN_USERNAME	✅	Your Garmin account email
GARMIN_ACCOUNT	❌	Lowercase local alias used for the implicit Web/CLI/MCP session path (default when omitted)
GARMIN_PASSWORD	✅*	Legacy direct-login password; do not use this for the interactive MFA setup below
GARMIN_SESSION_TOKEN	✅*	Inline pre-authenticated token (supported, but the session file is safer)
GARMIN_SESSION_TOKEN_FILE	✅*	Path to the owner-only DI v2 (or compatible legacy OAuth) session file generated by the local auth command
GARMIN_REGION	❌	global (default) or cn for Garmin China
GARMIN_FIT_DOWNLOAD_DIR	FIT only	User-selected host parent directory for FIT exports; no default. The generated account directory includes GARMIN_REGION
GARMIN_CACHE_TTL	❌	Cache duration in seconds (default: 300)
GARMIN_REQUEST_TIMEOUT_MS	❌	Garmin request timeout in milliseconds (default: 15000)
GARMIN_LOG_LEVEL	❌	debug | info | warn | error
GARMIN_ACTIVITY_DETAIL	❌	compact (default) or full (expanded fitness plus precise route/location fields; credentials and account/social identifiers are filtered)

* Normal data access needs one of GARMIN_PASSWORD, GARMIN_SESSION_TOKEN,
or GARMIN_SESSION_TOKEN_FILE. The experimental local Web, auth:serve, and
standalone MCP flows may start without one and create the implicit account
session file. A protected file is safer than an inline token,
especially when isolating multiple processes; this does not make the experimental
MFA bootstrap a release-supported workflow. If more than one is configured, the inline token takes
precedence over the file until Garmin explicitly rejects it; a newly written,
account-matching session file can then take over on retry. A valid session
takes precedence over password login.

⚠️ If your password contains # or other special characters, wrap it in double quotes — otherwise # and everything after it will be treated as a comment:

GARMIN_PASSWORD="my#secret!pass"

GARMIN_SESSION_TOKEN and the contents of GARMIN_SESSION_TOKEN_FILE are as
sensitive as a password. Token export is intentionally not AI-callable; never
paste a token into an AI conversation.

Two-step verification — experimental local dsh preview

When dsh and its Web UI are running together on the same local machine, use the
China account or International account Garmin button in the top bar. The
selected button must match the process's configured GARMIN_REGION; a mismatch
fails before any Garmin page is opened. A matching selection opens a custom bridge on an ephemeral
127.0.0.1 port; that bridge, rather than the dsh page itself, embeds Garmin's
official GAuth page. Email, password, MFA code, and any CAPTCHA are entered only
inside the Garmin iframe.

Garmin sends its short-lived service ticket only to the isolated loopback bridge.
The bridge validates the expected region, message origin, iframe source, service,
and ticket, then immediately hands it to the plugin Host for the region-bound DI
token exchange. Garmin China may bind an MFA ticket to the exact current
http://127.0.0.1:<port> bridge instead of the fixed Garmin embed URL; the
plugin preserves that ticket/service pair unchanged and rejects every other
loopback host, port, path, query, or region before contacting DI. It never
rewrites or retries the one-time ticket with a fallback service. The Host probes the Garmin profile, shows a sanitized profile to
the user, and asks them to confirm that it corresponds to the configured email.
Only then does it atomically save an owner-only session bound to the configured
account and region. The outer dsh page receives only
public progress states: the dsh page, model context, and AI-callable tool results
never receive the ticket, DI token, password, MFA code, or CAPTCHA response.

After the Host verifies the account through password login, a profile-bound DI
session, or a newly confirmed Web login, the matching region button subtitle
shows the verified account email as signed in; the other region keeps its
domain. Merely loading an identity-unverified legacy OAuth token does not show
this state, and the status endpoint never returns a ticket or token. The local
page refreshes this state every 15 seconds and whenever the window regains focus,
so later credential rejection or a successful lazy login updates the subtitle.

When the Host reports a missing, expired, or rejected session, or password
login returns positive MFA/CAPTCHA page evidence, the local page automatically
opens the configured region's auth dialog once. Closing it does not reopen the
same requirement revision; only a new state can trigger another automatic open.
The SDK's ambiguous no-ticket text, a password HTTP 401, generic sign-in HTML,
network errors, and MFA-looking titles do not trigger browser authentication.
While unauthenticated, the page polls this coarse data-free state once per
second; after login it returns to the 15-second account refresh.

Configure GARMIN_USERNAME and the correct GARMIN_REGION before opening the
dialog. GARMIN_SESSION_TOKEN_FILE is optional for this Web flow: when omitted,
the Host uses GARMIN_ACCOUNT (default default) and writes
~/.config/dsh-plugin-garmin-connect/accounts/<alias>.session.json on the usual
POSIX configuration path (or the platform configuration root). After a confirmed
write, the running plugin clears any earlier rejected-session state; the next
tool call reads the new file without requiring a dsh restart.

This Web flow is intentionally limited to the loopback dsh Web UI. It is not a
remote, hosted, or tunneled login endpoint. Browser third-party-cookie and iframe
policies can prevent Garmin GAuth from completing. A real China-region MFA run
passed the browser, DI exchange, profile confirmation, owner-only persistence,
and read-only session-consumption chain locally on 2026-08-29; International
MFA and refresh-token rotation remain unverified. Treat the flow as experimental,
not as a production recovery guarantee. Login, MFA, and profile confirmation
must finish within the bridge's 10-minute lifetime.

See the target architecture for two-step verification
for the complete trust boundary and data flow.

Local system-browser authentication — preview

The recommended local preview for CLI and MCP clients is the loopback broker.
Choose the account alias and region explicitly. For this command, both flags
are required and GARMIN_ACCOUNT/GARMIN_REGION are deliberately not used as
defaults, preventing a two-account setup from writing the wrong session:

# Installed executable
garmin-connect-auth serve --account personal --region global --open
garmin-connect-auth serve --account personal-cn --region cn --open

# Source checkout
npm run auth:serve -- --account personal --region global
npm run auth:serve -- --account personal-cn --region cn

serve starts a one-shot bridge on a random 127.0.0.1 port and opens it in
the system's default browser. It does not create or manage an isolated
Chrome/Playwright profile; the operating system may reuse an already-running
browser or start the configured default browser. The CLI may read the configured account email, but the
password, MFA code, and any CAPTCHA remain on Garmin's page; they cannot be
supplied through flags, environment variables, MCP tool arguments, or model
input. The bridge receives only the short-lived service ticket and hands it to
the local runtime for the region-bound DI exchange. The page then displays a
sanitized profile for confirmation before the runtime writes the owner-only
session. Login, MFA, and profile confirmation must finish within 10 minutes;
after that, start a new flow.

When GARMIN_SESSION_TOKEN_FILE is omitted, the output path is derived from
GARMIN_ACCOUNT/--account:
~/.config/dsh-plugin-garmin-connect/accounts/<alias>.session.json on the usual
POSIX configuration path (or the platform configuration root). The process can
then use only the non-password configuration below:

[email protected]
GARMIN_ACCOUNT=personal
GARMIN_REGION=global
GARMIN_FIT_DOWNLOAD_DIR=/absolute/path/to/garmin-fit-parent

This browser bootstrap remains a preview. The real China-region chain passed
locally on 2026-08-29, but International-region MFA and refresh-token rotation
are still pending, so do not treat it as a production recovery guarantee.

Legacy browser diagnostics

garmin-connect-auth login --browser is retained only for development and
diagnosis; it is not the recommended fallback for serve or MCP authentication.
It launches an isolated Chrome context through Playwright and may encounter
redirect interception failures. The non-persisting canary exercises the same
legacy path:

garmin-connect-auth login --browser --account personal --region global
garmin-connect-auth login --browser --account personal-cn --region cn
npm run auth:canary -- --region global
npm run auth:canary -- --region cn

The direct terminal-password attempt without --browser remains for
compatibility. Leaving its password prompt blank opens the shared system-browser
flow; positive MFA/CAPTCHA page evidence switches to that same flow without
asking for a terminal MFA code. Ambiguous password, network, and no-ticket
failures do not auto-open a browser. These diagnostics do not change the preview
status of MFA bootstrap.

DI v2 files bind the normalized username, region, and probed Garmin profile via
one-way hashes, including profileIdHash; they do not duplicate the plaintext
email in the binding. The runtime rejects username, region, or profile mismatch
before publishing refreshed credentials. It refreshes access tokens before
expiry, persists a rotated refresh token before using the new session, and may
retry an authentication failure at most once for an idempotent GET. Workout and
other write requests are never replayed automatically.

For backward compatibility, legacy session files containing only the two
oauth1 and oauth2 fields are still accepted. They have no profile binding;
the intended replacement is a validated DI v2 session with the mismatch guard,
but browser-generated DI v2 sessions remain preview functionality rather than a
release-supported production recovery guarantee.
On POSIX, a legacy file must still pass the current owner-only file-permission
check (normally mode 0600), complete safe ancestor-chain validation, and a
private final-parent check (normally mode 0700).

On POSIX, the default account directory is prepared before Garmin authentication
opens. To choose a different session file, add
--output /absolute/private/path/personal.session.json. Preflight canonicalizes
any safe existing link target, rejects unsafe/writable ancestors, requires the
final parent to belong to the effective UID with owner write+execute and no
group/other access (normally mode 0700), and creates missing components one at
a time as 0700. The writer uses that canonical destination and rechecks the
parent, existing destination, and no-follow temporary-file handle before the
atomic replacement. On macOS, granting extended ACL entries are rejected on
every checked ancestor, parent, existing file, and empty temporary file; a
private-looking 0700/0600 mode does not override that result.
If the normal configuration root or one of its ancestors is group/world-writable,
preflight intentionally refuses to start authentication. Repair that directory's
permissions yourself or set GARMIN_SESSION_TOKEN_FILE/--output to a fresh
owner-private application directory; the plugin will not silently chmod a
shared or broadly writable configuration tree.

On Windows, the implicit account path prefers the current user's local
LOCALAPPDATA root over redirected roaming APPDATA. Keep any explicit
destination beneath the current user's local OS profile/config root and use a
fresh dedicated subtree; UNC/network destinations are not supported. From the longest matching Windows
special-folder root down to the session parent, every component must have a
protected DACL owned by the current SID with exactly one current-SID
FullControl rule. Missing components are created atomically with that DACL;
non-exact existing components and every reparse point are rejected rather than
rewritten. The empty temporary file receives the same exact file DACL before
credential bytes are written, and the entire directory chain plus file ACL is
verified again when a session is read. Marker-only directories from earlier
previews are not trusted; migrate to a fresh dedicated subtree.

Multiple accounts: one isolated process per account

The supported runtime model is one account per process and one independently
initialized session per process. Give each dsh, Codex, Claude Code, or other MCP
process its own GARMIN_USERNAME, GARMIN_REGION, and GARMIN_ACCOUNT (or an
explicit GARMIN_SESSION_TOKEN_FILE). Each process can lazily use its implicit
account session path; browser MFA bootstrap remains a preview, with only the
China-region real-account chain verified so far.

Do not copy one session file to another process, and do not let simultaneous
processes share one file. Garmin refresh tokens may rotate; concurrent writers
can otherwise invalidate or overwrite each other's credentials. For example,
use aliases such as personal-dsh, personal-codex, and personal-claude, with
an independently initialized session for each one. Do not point another runtime
at the same file through a symbolic link or a differently cased path alias.

The processes may share one GARMIN_FIT_DOWNLOAD_DIR parent: the plugin creates
a separate account subdirectory from each configured region and email. This also
keeps cn and global accounts with the same email from colliding. For one MCP
entry, ordinary Garmin questions use that entry as the default. For two entries,
name them garmin-cn and garmin-global; mention the server name only when the
intended account is ambiguous.

This is process isolation, not an in-process account selector or a multi-tenant
authorization system. Do not expose one shared MCP process to mutually
untrusted users; per-user access control has not been implemented. Switching
accounts inside one conversation and automatic cross-account sync remain on the
roadmap.

FIT downloads

download_garmin_activity_fit accepts only an activity ID; the model cannot
choose an arbitrary output path. Garmin's original activity ZIP is downloaded
to a private temporary location, size-checked, and required to contain exactly
one valid FIT file. Given a configured parent directory <base>, the result is
written as <base>/GARMIN_FIT_<cn|global>_<normalized-email>/<activityId>.fit without
overwriting an existing file. The cn or global component comes from
GARMIN_REGION. Here <normalized-email> is derived safely from the configured
email: a normal email address
remains recognizable, while path separators, control characters, and other
unsafe filename characters are normalized before the account directory is
created. The user locates the file from the configured parent plus this rule.
The tool returns only activityId, fileName, sizeBytes, and sha256; it does
not return the parent, account directory, email, or full path. ZIP/FIT bytes
never enter model context.

The parent directory has no default and must be chosen explicitly through
GARMIN_FIT_DOWNLOAD_DIR. It is required only when using this tool; if unset,
the tool fails before writing any file and all other Garmin tools remain
available. Multiple account processes can safely share the same parent because
their region-and-normalized-email subdirectories are isolated, including when
the same email is used for both Garmin China and Garmin International.
Existing GARMIN_FIT_<email> directories are not migrated automatically; new
downloads use the region-prefixed directory while old files remain in place.

Garmin's “original” export is not guaranteed to be FIT. If the archive has no
single valid FIT entry, the tool fails safely instead of renaming another
format.

4. Run

npx --legacy-peer-deps=false @deepseek-ai/dsh web

Open http://127.0.0.1:3080. The plugin is loaded when Settings → Plugins → Plugin list shows plugin-garmin-connect as mounted & enabled. Then try: "How was my sleep last night?" or "Show me my last 5 runs."

5. Integration Test (optional, source checkout only)

The integration script is a development aid and is not included in the npm
tarball. From a source checkout with development dependencies installed, you
can run it after configuring .env:

npm run test:integration

The script checks read-only APIs and exits non-zero if any check fails. It does
not create, update, or delete workouts or other Garmin data.

By default it hides the account identifier and prints only counts/status, not
activity or health values. Set GARMIN_INTEGRATION_VERBOSE=true only when you
explicitly want normalized details in your local terminal output.

📋 Click to expand sample output

🔌 Garmin Connect Integration Test
   Domain : garmin.com
   User   : configured (identifier hidden)
   Date   : 2026-08-18
   Scope  : read-only (workout creation/update/deletion is not tested)

── 1. Authentication ──
  ✅ Password login successful

── 2. Activities ──
  ✅ Got 3 activities

── 3. Sleep ──
  ✅ Sleep data loaded

── 4. Steps ──
  ✅ Step data loaded

── 5. Heart Rate ──
  ✅ Heart-rate data loaded

── 6. Weight / Body Composition ──
  ✅ Body-composition data loaded

── 7. Workout Library ──
  ✅ Got 5 workout templates

── 8. User Profile ──
  ✅ Profile loaded

🏁 Integration test complete: 8 passed, 0 failed.
   Write operations were intentionally not tested.

---

Security

Credentials are used locally to authenticate directly with Garmin Connect
and are never returned by an AI tool.

Credential Resolution Order

1. Plugin config values (set on the plugin row in a profile patch / `--patch` overlay)
   ↓ fallback
2. Environment variables (.env / shell)
   ↓ fallback
3. Schema defaults

Best Practices

Practice	Status
Environment-variable and secret-marked configuration are supported	✅
.env is in .gitignore	✅
Account identifier and credentials marked with role('secret') in Cordis schema	✅
Local dsh Web MFA bridge	⚠️ Experimental; loopback only; real China-region MFA chain passed locally, International pending
CLI serve and MCP URL elicitation	⚠️ Experimental; shared runtime verified with real China-region MFA, concrete MCP-client and International runs pending
Legacy CLI login --browser / canary	⚠️ Playwright diagnostics only; not an authentication fallback
DI v2 sessions bind username, region, and profileIdHash; legacy two-field sessions remain compatible	✅
Independently initialized per-process session files support isolated multi-account setups	✅
Access refresh is preemptive; idempotent GET replay is limited to once and writes are never replayed	✅
Tool outputs never include raw credentials	✅
FIT bytes and local/account paths stay on the host; the model receives only activity/file name/size/hash	✅
In-memory cache reduces API calls (rate-limit protection)	✅

Session Tokens

Session-token authentication remains supported, but tokens are credentials and
must not appear in agent output or trajectory logs. For that reason this plugin
does not expose authentication, MFA submission, or token export as AI-callable
tools. If you already have a validated owner-only DI v2 or compatible legacy
session file, dsh/MCP can read it through GARMIN_SESSION_TOKEN_FILE; the
runtime does not need the account password. The DI file binds normalized
username and region as well as profileIdHash; legacy unbound
oauth1/oauth2 files remain readable for compatibility. Creating a new MFA
session through the dsh Web bridge, serve, or MCP URL elicitation remains
experimental and is not yet release-supported. Because Garmin
refresh tokens may rotate, never concurrently share or copy one session file
across dsh, Codex, Claude Code, or other processes.

---

Use with Other AI Coding Agents (MCP)

This plugin also ships as a standalone MCP (Model Context Protocol) server, so you can use the same Garmin tools with OpenAI Codex, Claude Code, Claude Desktop, Cursor, Windsurf, WorkBuddy, ZCode, and any other MCP-compatible client — no DeepSeek Harness required.

Current availability: the standalone MCP entry point is included in npm
0.1.5 and later. A local checkout remains useful for development.

Build the local server first:

git clone https://github.com/Likenttt/garmin-connect-plugin-for-dsh.git
cd garmin-connect-plugin-for-dsh
npm install
npm run build

Replace /absolute/path/to/garmin-connect-plugin-for-dsh in the examples with
the checkout's actual absolute path.

The MCP process needs an email, explicit region, and local account alias. A
session-file path is optional: when omitted, the server derives an owner-only
path from GARMIN_ACCOUNT. Make these values and any FIT parent directory
available to the client process:

export GARMIN_USERNAME='[email protected]'
export GARMIN_REGION='global'
export GARMIN_ACCOUNT='personal'
export GARMIN_FIT_DOWNLOAD_DIR='/absolute/path/to/garmin-fit-parent'
# Optional override; otherwise accounts/personal.session.json is used.
# export GARMIN_SESSION_TOKEN_FILE='/absolute/path/to/personal.session.json'

Do not put a password or MFA code in these variables. If a tool encounters
a missing, expired, or rejected session, or an explicit MFA/CAPTCHA browser
challenge, and the client advertises MCP URL
elicitation, the tool call returns a random local 127.0.0.1 sign-in URL. Open
that URL, finish Garmin login/MFA and profile confirmation in the browser, wait
for the completion notification, then retry the original request. The server
does not automatically replay it, so a write can never be duplicated by this
flow. Clients without URL elicitation receive the equivalent trusted-terminal
fallback command:

If a legacy GARMIN_PASSWORD is still present, successful password-only login
continues to work. Only positive MFA input/form or active CAPTCHA markup is
converted to the same browser-recoverable MCP authentication state. The SDK's
ambiguous no-ticket text, a wrong password, HTTP 401, and network failures are
not treated as MFA; the password and upstream error text never enter the tool
result.

garmin-connect-auth serve --account personal --region global --open

If that MCP entry explicitly sets GARMIN_SESSION_TOKEN_FILE, export the same
value in the trusted terminal or append --output with that same destination.
The fallback error deliberately does not echo the local path into model
context. After serve commits a changed, account-matching session, retrying the
tool hot-loads that exact file snapshot in the already-running MCP process; an
MCP restart is not required. An unchanged rejected file, an expired replacement,
or a file for another account is never probed again. If an inline
GARMIN_SESSION_TOKEN was explicitly rejected, this safe replacement also
supersedes it in memory; the rejected inline credential is not retried.

The authentication page, not the MCP tool or model, receives the password and
MFA code. Protect the resulting session file and FIT directory because they can
grant account access or contain precise location and health data. Each
simultaneously running client process needs its own alias/session; do not copy
or concurrently share one file across Codex, Claude Code, dsh, or another
client. Browser MFA remains a preview as noted above; only the China-region
real-account chain has been verified so far.

OpenAI Codex (app, CLI, and IDE extension)

Codex clients on the same host share ~/.codex/config.toml. The recommended
setup forwards credential variable names from the environment instead of
copying their values into TOML. With the variables above available to the Codex
process, add this entry to ~/.codex/config.toml:

[mcp_servers.garmin-connect]
command = "node"
args = ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"]
env_vars = ["GARMIN_USERNAME", "GARMIN_REGION", "GARMIN_ACCOUNT", "GARMIN_SESSION_TOKEN_FILE", "GARMIN_FIT_DOWNLOAD_DIR"]

# Read tools can run normally; Codex asks before local-file and Garmin writes.
default_tools_approval_mode = "writes"

This entry uses the session assigned only to this Codex process. When Codex
advertises URL elicitation, it may surface the local sign-in link described
above; otherwise initialize the same alias with garmin-connect-auth serve.
The password/MFA code stays on Garmin's page. Do not reuse a session already
assigned to dsh, Claude Code, or another running process. For China and
International accounts, add separately configured entries named, for example,
garmin-cn and garmin-global. They may reuse the same FIT parent; output is
automatically isolated under that account's region-and-normalized-email
subdirectory.

The Codex process must inherit the exported variables. If the desktop app was
launched outside that shell, add the server through Settings → MCP servers
and provide its environment there, or launch it through your usual secret-aware
environment. Values entered in Settings are local credentials; protect the
resulting configuration file.

For a trusted-project-only setup, put the same table in .codex/config.toml
inside that project. Restart the Codex client after editing the file, then
inspect the saved configuration:

codex mcp list
codex mcp get garmin-connect

Inside Codex CLI, use /mcp to verify that the server is active and inspect
its tools. The
official Codex MCP documentation
also covers the Settings UI and codex mcp add command.

Claude Code

Garmin is normally a personal server, so user scope is a good default. The
following bash/zsh example keeps the session contents out of ~/.claude.json;
only the owner-only file path is configured:

claude mcp add-json --scope user garmin-connect \
  '{"type":"stdio","command":"node","args":["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],"env":{"GARMIN_USERNAME":"${GARMIN_USERNAME}","GARMIN_REGION":"${GARMIN_REGION:-global}","GARMIN_ACCOUNT":"${GARMIN_ACCOUNT:-default}","GARMIN_SESSION_TOKEN_FILE":"${GARMIN_SESSION_TOKEN_FILE}","GARMIN_FIT_DOWNLOAD_DIR":"${GARMIN_FIT_DOWNLOAD_DIR}"}}'

This server uses a session assigned specifically to this Claude Code process.
If the client does not surface MCP URL elicitation, initialize it with the
trusted-terminal serve command; password/MFA input remains on Garmin's page.
Register a differently named server and provide a distinct independently
initialized session file for each additional process or account. Do not copy
another process's session. The servers may reuse the same FIT parent directory.

Use --scope local instead if the server should be available only in the
current project. Keep the path variables available whenever you launch Claude
Code, then verify the connection:

claude mcp get garmin-connect
claude mcp list

Inside Claude Code, /mcp shows connection status and the exposed tools. See
the official Claude Code MCP documentation
for scope and .mcp.json details. Do not commit personal Garmin credentials in
a project-scoped configuration.

Using the tools in Codex or Claude Code

Once garmin-connect reports as connected, ask naturally; the client selects
the MCP tool. If tool selection is ambiguous, explicitly say “use the
garmin-connect MCP server.” For example:

• “Use garmin-connect to show my last five runs.”
• “Compare my sleep and resting heart rate over the last seven days.”
• “Download the FIT file for activity 123456789 under my configured Garmin FIT parent.”
• “Preview a threshold workout, show me the steps, and do not create it until I approve.”

Workout creation still follows the enforced two-call confirmation flow: the
first call only previews, and creation requires your approval plus the returned
one-time confirmationId.

Claude Desktop

Edit ~/Library/Application Support/Claude/claude_desktop_config.json (macOS) or %APPDATA%\Claude\claude_desktop_config.json (Windows):

{
  "mcpServers": {
    "garmin-connect": {
      "command": "node",
      "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
      "env": {
        "GARMIN_USERNAME": "[email protected]",
        "GARMIN_REGION": "global",
        "GARMIN_ACCOUNT": "personal",
        "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
        "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
      }
    }
  }
}

Restart Claude Desktop. You'll see a 🔌 icon indicating the tools are loaded. Try: "Show my last 5 runs" or "Preview a threshold workout".

Cursor

Add the same mcpServers.garmin-connect object shown above to the workspace's
.cursor/mcp.json, using the absolute lib/mcp.js path.

Windsurf

Open Windsurf Settings → Cascade → MCP Servers, or edit
~/.codeium/windsurf/mcp_config.json, and add the same
mcpServers.garmin-connect object shown above.

WorkBuddy

WorkBuddy Desktop supports local MCP servers at user and project scope. For
personal Garmin data, prefer the user-level ~/.workbuddy/mcp.json. Open
Plugins → MCP Servers → Configure MCP, or edit that file directly, and add:

{
  "mcpServers": {
    "garmin-connect": {
      "command": "/absolute/path/to/node",
      "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
      "env": {
        "GARMIN_USERNAME": "[email protected]",
        "GARMIN_REGION": "global",
        "GARMIN_ACCOUNT": "personal",
        "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
        "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
      }
    }
  }
}

Use command -v node on macOS/Linux or where node on Windows to find the
absolute Node.js executable; GUI applications may not inherit an nvm shell
path. In JSON on Windows, use forward slashes such as C:/.../node.exe, or
escape each backslash as \\. Leave out type in WorkBuddy's local-command
format. Save the file and confirm that the server status turns green, then start
with a read-only request. See the official WorkBuddy MCP guide.

The session file in this entry must be independently initialized; a client that
does not surface URL elicitation uses the trusted-terminal serve command.
WorkBuddy and the model never receive the password/MFA code. Add another named
mcpServers entry with a separate session file per account. Entries may share
the same FIT parent directory because region-and-email account subdirectories
are automatic.

ZCode

Open Settings → MCP Servers → New MCP Server, choose User scope and
stdio, then enter the same absolute Node.js command, lib/mcp.js argument,
and Garmin environment variables. Alternatively, edit the native user config
at ~/.zcode/cli/config.json:

To test this release candidate directly from npm, use an absolute npx path
as the command and these arguments instead of a checkout's lib/mcp.js:

-y --package [email protected] garmin-connect-mcp

Do not configure GARMIN_PASSWORD; with a missing session, the first read-only
tool call can exercise ZCode's URL-elicitation path. Keep the explicit
owner-only GARMIN_SESSION_TOKEN_FILE shown below.

{
  "mcp": {
    "servers": {
      "garmin-connect": {
        "command": "/absolute/path/to/node",
        "args": ["/absolute/path/to/garmin-connect-plugin-for-dsh/lib/mcp.js"],
        "env": {
          "GARMIN_USERNAME": "[email protected]",
          "GARMIN_REGION": "global",
          "GARMIN_ACCOUNT": "personal",
          "GARMIN_SESSION_TOKEN_FILE": "/absolute/path/to/personal.session.json",
          "GARMIN_FIT_DOWNLOAD_DIR": "/absolute/path/to/garmin-fit-parent"
        }
      }
    }
  }
}

ZCode can also import an existing Codex or Claude Code MCP entry. Its generic
~/.agents/mcp.json support uses the mcpServers shape, but if the same scope's
.zcode config contains any MCP server, ZCode skips that .agents file rather
than merging it. See the official ZCode MCP guide.

The session file in this entry must be independently initialized; a client that
does not surface URL elicitation uses the trusted-terminal serve command.
ZCode and the model never receive the password/MFA code. Add another named server with
a separate session file per account. Servers may share the same FIT parent
directory because region-and-email account subdirectories are automatic.

These configurations have been checked against both clients' published schemas;
an end-to-end WorkBuddy/ZCode smoke test with a real Garmin account has not yet
been recorded.

The Claude Desktop, Cursor, Windsurf, WorkBuddy, and ZCode JSON examples store
the sensitive session-file path in their client configuration, but not the
session contents, password, or MFA code. Restrict those files' permissions and
never commit them. The Codex and Claude Code examples forward path variables
instead. MCP results can place sleep, heart-rate, weight, activity, and location
data in the selected model's context; review that client's data controls and
keep activity detail at compact unless precise expanded data is necessary.
FIT bytes and the complete local/account path remain on the MCP host. Only the
activity ID, file name, size, and hash enter model context; locate the file
using your configured parent and the documented account-directory rule.

With npm 0.1.5 or later, the local node …/lib/mcp.js command can be replaced
with:

npx -y --package dsh-plugin-garmin-connect garmin-connect-mcp

Manual Run

# Run the MCP server (stdio); the account session path is derived lazily.
GARMIN_USERNAME=xxx \
GARMIN_ACCOUNT=personal \
GARMIN_REGION=global \
GARMIN_FIT_DOWNLOAD_DIR=/absolute/path/to/garmin-fit-parent \
node lib/mcp.js

The MCP server exposes the same 10 tools and argument semantics as the dsh
plugin: activities, sleep, steps, heart rate, weight, workout-library templates,
profile, running skills, local FIT download, and workout preview/creation.
No AI-callable tool accepts a password/MFA code or exports a session token.
Browser authentication is an out-of-band local URL elicitation, and the user
must retry the original tool after completion.

---

Architecture

┌─────────────────────────────────────────┐
│         DeepSeek Harness (dsh)          │
│                                         │
│  ┌───────────────────────────────────┐  │
│  │     dsh-plugin-garmin-connect     │  │
│  │                                   │  │
│  │  ┌─────────┐    ┌─────────────┐  │  │
│  │  │  Config  │───▶│ GarminClient│  │  │
│  │  │ (Schema) │    │  (cached)   │  │  │
│  │  └─────────┘    └──────┬──────┘  │  │
│  │                        │         │  │
│  │  ┌─────────────────────▼───────┐ │  │
│  │  │      Tool Registry (10)     │ │  │
│  │  │  • get_garmin_activities    │ │  │
│  │  │  • get_garmin_sleep         │ │  │
│  │  │  • get_garmin_steps         │ │  │
│  │  │  • get_garmin_heart_rate    │ │  │
│  │  │  • get_garmin_weight        │ │  │
│  │  │  • get_garmin_workouts      │ │  │
│  │  │  • get_garmin_profile       │ │  │
│  │  │  • get_running_skill_advice │ │  │
│  │  │  • download activity FIT    │ │  │
│  │  │  • create_garmin_workout    │ │  │
│  │  └─────────────────────────────┘ │  │
│  └───────────────────────────────────┘  │
│               Cordis Runtime            │
└────────────────┬────────────────────────┘
                 │
      ┌──────────┴──────────┐
      ▼                     ▼
connect.garmin.com    MCP Server (stdio)
connect.garmin.cn     → Claude Desktop / Claude Code /
                        Codex / Cursor / Windsurf /
                        WorkBuddy / ZCode

Target architecture for two-step verification

The architecture gives dsh Web, MCP clients, and the CLI one shared local
authentication runtime while keeping Garmin credentials out of AI conversations:

┌──────────────────┐  ┌──────────────────┐  ┌──────────────────┐
│ dsh Web          │  │ MCP tool call    │  │ CLI serve        │
│ region/auth state│  │ URL elicitation  │  │ system browser   │
└────────┬─────────┘  └────────┬─────────┘  └────────┬─────────┘
         └─────────────────────┼─────────────────────┘
                               ▼
          LocalAuthBroker + EmbeddedAuthController
                               │
                               ▼
          random one-shot 127.0.0.1 bridge
          flowId + CSRF + strict CSP + 10-minute TTL
                               │ embeds the exact regional page
                               ▼
          official Garmin GAuth iframe (cn / global)
          email, password, MFA, and CAPTCHA stay here
                               │
                               │ one-time ticket + original exact service
                               ▼
          Host validates origin / iframe / CSRF / ticket / service
                               │
                               ▼
          regional DI exchange → profile probe → user confirmation
                               │
                               ▼
          atomically persist an owner-only DI v2 session
          bound to account, region, and profile; never shared by processes
                               │
                               ▼
          GarminClient hot-load / safe refresh
                               │
                               ▼
          user explicitly retries the original tool call

The non-negotiable boundaries are:

• The outer dsh page, MCP client, and model see only a one-time local URL,
  completion notification, or coarse non-sensitive status. Tickets, DI tokens,
  session contents, and session paths never enter model context or AI tool
  arguments/results.
• The bridge accepts only the expected Garmin SSO origin, iframe window, CSRF,
  and an exactly matched ticket/service pair. It never rewrites the service,
  follows a redirect, or retries a one-time ticket against a fallback.
• Before saving a session, the Host probes the Garmin profile and asks the user
  to confirm the account. It then writes the session atomically with private
  permissions. A running client hot-loads only a changed, account-matching,
  validated session.
• Authentication never replays the original tool automatically, preventing
  duplicate FIT downloads or workout writes. Failure, cancellation, or timeout
  ends the flow; another attempt creates a new flow.
• Refresh may replay a safe GET at most once. It first verifies the same profile
  and persists rotated tokens; writes are never replayed after refresh.

[!WARNING]
This is the target architecture and the boundary followed by the current
experimental implementation. A real China-region MFA → exact ticket/service
→ DI exchange → profile confirmation → private session write → fresh-client
read chain has passed locally. Real International MFA, real refresh-token
rotation, and complete URL-elicitation UX in more MCP clients remain pending.
The design is same-machine loopback only, not a remote, multi-user, or hosted
authentication service.

---

Development

# Clone & install
git clone https://github.com/Likenttt/garmin-connect-plugin-for-dsh.git
cd garmin-connect-plugin-for-dsh
npm install

# Build
npm run build

# Watch mode
npm run dev

# Run tests
npm test

Project Structure

src/
├── index.ts          # Plugin entry point (Cordis apply function)
├── config.ts         # Configuration schema with env-var resolution
├── client.ts         # Garmin API wrapper with caching
├── account-session.ts # Implicit per-account session destination
├── auth.ts           # Private-SSO authentication flow with local MFA callback
├── auth-cli.ts       # Trusted local serve and legacy diagnostic commands
├── browser-auth-canary.ts # Isolated Chrome DI setup/canary core
├── embedded-auth-runtime.ts # Shared Web/CLI/MCP ticket-to-session runtime
├── local-auth-broker.ts # One-shot loopback/system-browser broker
├── di-session.ts     # DI runtime validation, refresh, and safe GET replay
├── session-store.ts  # Strict session-file loading and atomic private writes
├── darwin-private-acl.ts # Darwin extended-ACL verification
├── windows-private-acl.ts # Owner-only Windows SID/DACL enforcement
├── fit-export.ts     # Bounded, non-overwriting FIT extraction from original ZIP
├── tool-service.ts   # Shared tool behavior for dsh and MCP
├── mcp.ts            # Standalone MCP adapter for Codex/Claude Code/other clients
├── mcp-auth.ts       # URL elicitation, completion notification, and fallback
├── mcp-shutdown.ts   # Bounded stdio/signal cleanup for MCP auth
├── knowledge/
│   ├── running-skills.ts  # 8 workout types + 4 compact training philosophies
│   └── workout-schema.ts  # Workout definition → Garmin JSON builder
├── tools/
│   └── index.ts      # Tool definitions & registration (10 tools)
└── utils/
    ├── errors.ts      # Safe public errors and upstream-log redaction
    ├── cache.ts       # In-memory TTL/LRU cache with single-flight refresh
    ├── date.ts        # Local calendar-date parsing
    ├── path.ts        # FIT parent-directory expansion and resolution
    └── format.ts      # Raw-data → LLM-friendly formatters

---

Publishing & Distribution

The package is a standard dsh bundle: package.json declares dsh.bundle.patch → cordis.patch.yml, and files ships the compiled lib/, .env.example, both READMEs, and the patch file.

npm run build   # prepublishOnly also runs this automatically
npm publish

After publishing, users install with a single command:

npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add dsh-plugin-garmin-connect

Distribution notes:

• npm registry (recommended) — the tarball ships prebuilt lib/, so no build permission is needed at install time.
• Local checkout — npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add . links the source directory; run npm install first.
• GitHub installs — npx --legacy-peer-deps=false @deepseek-ai/dsh plugin --profile web add github:<owner>/<repo> fetches sources and runs the package's prepare script with the locally installed TypeScript compiler; pnpm ≥ 10 refuses to run the script until you allow it — dsh prints the exact allowBuilds key for the profile's pnpm-workspace.yaml.
• Add the dsh-plugin topic to your GitHub repository for discoverability.

---

Roadmap

• Body Composition — weight, BMI, body fat %
• Workout Library — list reusable Garmin workout templates
• Workout Creation — safely preview and create structured workout-library entries
• MCP Server — use with Codex, Claude Code/Desktop, Cursor, Windsurf, WorkBuddy, ZCode
• Running Coach — 8 workout types, 4 training philosophies, and mandatory personalized intake
• Browser MFA Bootstrap — China-region real MFA, DI v2 persistence, fresh-client session consumption, profile, and activity read passed locally; same-process hot loading is automated-covered; finish International MFA, refresh rotation, concrete MCP clients, and broader browser-policy verification
• Process-isolated Accounts — one independently initialized session file per dsh/MCP process; concurrent file sharing is unsupported
• FIT Download — safely extract one FIT from the original archive into an automatic region-and-normalized-email subdirectory under a user-selected parent
• Training Status — VO2 Max, training load, recovery time
• Single-process Account Registry — run an isolated client, cache, limiter, and bound session for every configured account alias
  • list_garmin_accounts — list aliases, regions, and connection status without exposing email addresses, tokens, or session paths
  • Add an optional account argument to account-sensitive tools; require an explicit alias when no safe selection exists
  • use_garmin_account — select an account for one conversation when dsh exposes a trusted conversation identity
  • Fall back to passing the selected alias on every tool call; never use a process-global active account
  • Add per-user account allowlists before describing the feature as multi-tenant isolation
• Multi-account Activity Sync — copy activities in one explicit direction between CN and Global accounts
  • Preview the source, target, date range, candidates, duplicates, and privacy impact before any upload
  • Bind a short-lived, one-time confirmation to the exact account pair and immutable activity manifest
  • Stage and validate FIT privately, then upload once to the explicitly selected target; never delete the source
  • Persist a sync ledger for exact deduplication, restart recovery, and unknown upload outcomes; never blindly retry a timed-out POST
  • Add bounded batch jobs with status, pause, and resume
  • Add opt-in polling schedules for one-way automatic sync while dsh is running, with catch-up after restart
  • Keep bidirectional sync, automatic deletion, and full Garmin metadata mirroring out of the first release
• Webhook / Push — real-time activity upload notifications
• OAuth 2.0 — migrate to official Garmin API when available for personal use

---

License

MIT

---

Acknowledgements

• DeepSeek Harness — the agentic coding runtime
• Cordis — the plugin lifecycle framework
• garmin-connect — unofficial Garmin Connect client for Node.js
• Thanks to Zhitao and DailySync for the inspiration

_{Product names and logos belong to their respective owners and are shown only to describe interoperability.}
