Serial Studio

English · 简体中文

A multi-form serial-port terminal — desktop, web, and remote. Built with Tauri + Rust + React.

Serial Studio lets you talk to serial devices from a polished desktop app, from any
browser on your network, or driven by an LLM over MCP — all backed by the same Rust core.
Multiple clients can share a single port, you can script repetitive exchanges as macros,
and label ports with device aliases.

✨ Features

• Multi-port terminal — concurrent ports in tabs or split side-by-side (VS Code-style editor groups), powered by xterm.js.
• Port sharing — multiple windows / clients attach to the same port. The first opener's
  config wins; later clients join read/write. Force-close kicks every holder off.
• Macros — step sequences (send / delay / expect / clear), importable / exportable
  as JSON so they travel between machines.
• Scripting — full JS control flow (retry / branching / loops / parsing) for what macros can't express. Runs on the open port; pass a port arg to drive several ports from one script. Declare runtime parameters and they're collected in a popup, so reruns need no code edits.
• Port aliases — label a port with the device it connects, e.g. GPS (COM7).
• Three ways in:
  • Local desktop app (IPC, bypasses the network entirely).
  • Web — open http://host:port/ in a browser; the UI is embedded in the binary.
  • Remote — connect a desktop window to another machine's Serial Studio.
• MCP — expose the serial port to LLMs (serial_list / send / read / grep /
  status / clear), addressable by port name or alias.
• Telnet — works with classic terminal clients.
• Instrumented UI — dark/light themes, in-terminal search (Ctrl+F), font zoom, RX/TX LEDs.

🧱 Architecture

Control plane and data plane are deliberately separated:

• Control plane (Tauri IPC) — settings, service lifecycle, alias & macro persistence.
• Data plane (axum) — WebSocket, MCP, Telnet; all adapters over the same
  SerialManager + EventBus.

Crates

🛠 Tech stack

Tauri 2 · Rust (edition 2021, axum, serialport, tokio) · React 18 · TypeScript · Vite · xterm.js

📋 Requirements

• Rust (stable)
• Node.js (for the frontend)
• Windows: WebView2 (preinstalled on Win 10/11)
• A serial port (real or virtual)

🚀 Getting started

# build frontend + release binary
npm install --prefix ui
cargo tauri build

# or run in dev (hot-reload frontend)
cargo tauri dev

The release artifact is serial-studio.exe.

📖 Usage

• Desktop — run serial-studio.exe.
• Web / in-browser — the app runs a server (WS 18700, Telnet 18701). From any machine
  on the LAN, open http://<host>:18700/; the UI is served from the binary itself.
• Remote window — from the desktop app, open a remote window to another Serial Studio host.
• Headless — serial-studio.exe --no-gui runs only the backend (no window).

First run (unsigned build): releases aren't code-signed yet.

• macOS — Gatekeeper blocks it. After dragging to /Applications, strip the quarantine flag:

  xattr -dr com.apple.quarantine "/Applications/Serial Studio.app"


• Windows — SmartScreen warns; click More info → Run anyway.

Updates: Windows and Linux builds self-update in-app (Help → About → Check for updates).
macOS does not auto-update — without Apple notarization, a self-replaced .app gets
re-blocked by Gatekeeper, so grab the new .dmg from the
Releases page manually.

⚙️ Configuration

Runtime config lives next to the binary:

🤖 MCP

POST /mcp speaks JSON-RPC. Twelve tools: 6 basic (serial_list, serial_send,
serial_read, serial_status, serial_grep, serial_clear), 2 script execution
(serial_debug_script for ad-hoc JS, serial_run_script to run a saved script by name —
both gated by enable_scripting), and 4 script library management (serial_save_script,
serial_get_script, serial_list_scripts, serial_delete_script — data-only, not gated).
The port argument accepts a real port name or an alias.
A serial_script_guide prompt documents the scripting API and constraints.

Connect from Claude Code

claude mcp add --scope user --transport http SerialStudio http://<host>:18700/mcp

Replace <host> with the machine running Serial Studio (127.0.0.1 for the local app).
Other MCP clients (Claude Desktop, etc.): add an HTTP MCP server pointing at the same URL.

Raw JSON-RPC

{
  "jsonrpc": "2.0", "id": 1, "method": "tools/call",
  "params": { "name": "serial_send", "arguments": { "port": "GPS", "data": "AT", "timeout_ms": 1000 } }
}

🔌 Board integration (custom device side)

You don't need the full serial-studio on the board: implement the device-side subset of the
remote-device protocol with a tiny program, register the board's address in the hub UI, and its
UARTs show up as nickname::port everywhere — Web UI, scripts and MCP tools (agents reach the
board straight through MCP).

• Protocol contract: docs/device-protocol.md (handshake / messages / binary data frames)
• Reference implementation: examples/ss-board-bridge.c — single-file C,
  libc only, musl-gcc -O2 -static produces a small static binary for any architecture.
• Prebuilt: static binaries for x86_64 / aarch64 / armv7 / riscv64 (plus a sha256 manifest)
  are attached to every Release — scp one to the board and run. For mips/mipsel, compile
  from source with a single musl-gcc command (see the protocol doc).

🔒 Security note

The server binds 0.0.0.0 by default and carries no authentication. Anyone who can reach
the port can open / send to your serial ports and read their output. Bind to 127.0.0.1 in
settings.json, or sit behind a firewall / VPN, for anything beyond a trusted LAN.

Remote JS scripting (WS run_script / MCP serial_debug_script + serial_run_script) is gated by enable_scripting
in settings.json, off by default. When enabled, any reachable client can execute JS
against your serial ports. The script sandbox only exposes the serial primitives
(send/expect/clear/sleep) — there is no file, network, or process access — but it can
still drive your devices arbitrarily and read their output. Keep it disabled on untrusted
networks.

The script library tools (serial_save_script / serial_get_script / serial_list_scripts /
serial_delete_script) are data management and always accessible regardless of
enable_scripting: any reachable client can read saved script code (which may embed host
paths, LAN addresses, or credentials in comments), overwrite, or delete it. Same trusted-LAN
rule applies.

📁 Project layout

serial-studio/
├─ crates/
│  ├─ core/        # ss-core: serial manager + port ownership + macros
│  ├─ server/      # ss-server: axum WS/MCP/Telnet + embedded SPA
│  └─ tauri-app/   # serial-studio: Tauri shell (control plane)
├─ ui/             # React + TS + Vite frontend
└─ Cargo.toml      # workspace

🤝 Contributing

Issues and pull requests welcome. This is a small project — keep changes scoped and match the
existing style.

📄 License

MIT — see LICENSE.
